Neumann M 147 TUBE | Cardioid Tube Mic with K47 Capsule, includes N149A, SG1, KT8 and Case Nickel

The Neumann M 147 TUBE Cardioid Tube Mic with K47 Capsule is a high-quality vacuum tube condenser microphone designed for professional audio recording. This mic stands out with its cardioid characteristic, which ensures excellent directional sensitivity. It incorporates the legendary K 47 dual diaphragm capsule, which has been inherited from iconic predecessors like the U 47 and the M 49. This ensures that the M 147 delivers the warm, rich, and detailed sound signature that Neumann microphones are renowned for.

The heart of the M 147 is an advanced tube technology functioning as an impedance converter, followed by a transformerless output circuit that ensures an extremely low self-noise level. This innovative combination of tube and solid-state circuitry earned the M 149 Tube a TEC Award in 1997, and the M 147 continues this legacy. The microphone is adorned with an elegant satin nickel finish, making it a visually appealing addition to any studio setup.

One of the standout features of the M 147 TUBE is its ability to feed extremely long microphone cables without any audio degradation. The microphone is provided as a complete set in a high-quality aluminum case, which includes a microphone cable, a metal swivel mount for a mic stand, and a compact universal power supply. Additionally, the modern manufacturing process allows Neumann to offer this high-performance microphone set at an attractive price point.

Key Features

• Universal tube microphone
• Pressure gradient transducer with the large-diaphragm capsule of the legendary U 47 and M 49
• Transformerless circuitry
• Low self-noise level
• Comes with a metal swivel stand mount, universal power supply, and cable in an attractive aluminum case

Specifications

• Acoustical operating principle: Pressure gradient transducer
• Directional pattern: Cardioid
• Frequency range: 20 Hz ... 20 kHz
• Sensitivity at 1 kHz into 1 kohm: 20 mV/Pa
• Rated impedance: 50 ohms
• Rated load impedance: 1 kohms
• Equivalent noise level, CCIR: 24 dB
• Equivalent noise level, A-weighted: 12 dB-A
• Signal-to-noise ratio, CCIR (rel. 94 dB SPL): 70 dB
• Signal-to-noise ratio, A-weighted (rel. 94 dB SPL): 82 dB-A
• Maximum output voltage: 8 dBu
• Dynamic range of the mic. amplifier (A-weighted, 0.5 %): 102 dB
• Dynamic range of the mic. amplifier (A-weighted, 5 %): 122 dB
• Powering: Power supply N 149 A
• Matching connector: XLR 3F
• Weight: 460 g, 1 lbs
• Diameter: 57 mm
• Length: 142 mm

Package Contents

• Neumann M 147 TUBE Cardioid Tube Microphone
• Universal power supply (N 149 A)
• Microphone cable (KT 8)
• Swivel stand mount (SG1)
• Aluminum case
