VigilLink 8K HDMI 2.1 HDBaseT 3.0 Extender with USB 2.0 Support
VigilLink 8K HDMI 2.1 HDBaseT 3.0 Extender with USB 2.0 Support
Free Shipping
VigilLink VLEX-HT3200U-TR: 8K HDMI 2.1 HDBaseT 3.0 Extender with USB 2.0 Support
The VigilLink VLEX-HT3200U-TR is a cutting-edge HDBaseT 3.0 extender designed to deliver unparalleled video and audio transmission capabilities. Fully compliant with HDMI 2.1 and HDCP 2.3 standards, this extender supports an impressive 40 Gbps Fixed Rate Link (FRL) and 18 Gbps Transition-Minimized Differential Signaling (TMDS), ensuring seamless transmission of high-quality signals. Whether you're aiming for 8K resolution at 30 frames per second (4:4:4) with 10-bit color depth or 4K at 120Hz (4:4:4) with 10-bit color, the VLEX-HT3200U-TR guarantees crystal-clear visuals that meet the demands of modern high-definition content.
Beyond its exceptional video capabilities, the VLEX-HT3200U-TR is equipped with Variable Refresh Rate (VRR), Fast Vactive (FVA), and Auto Low Latency Mode (ALLM) support. These features collectively enhance the viewing experience by reducing screen tearing, minimizing latency, and ensuring smooth video playback. Additionally, the extender offers comprehensive High Dynamic Range (HDR) support, including HDR10, HDR10+, Dolby Vision, and Hybrid Log-Gamma (HLG) pass-through, providing vibrant and lifelike images that captivate viewers.
Designed for versatility and reliability, the VLEX-HT3200U-TR facilitates video distribution over distances up to 328 feet (100 meters). It supports Enhanced Audio Return Channel (e-ARC) from receiver to transmitter, ensuring high-quality audio transmission. The inclusion of USB 2.0 with speeds up to 350 Mbps caters to peripheral connectivity needs, while bi-directional Ethernet (1Gb), analog audio, Infrared (IR), and RS-232 pass-through functionalities offer comprehensive control and communication options. Furthermore, the bi-directional Power over Cable (PoC) feature allows power to be supplied to extenders from either the transmitter or receiver, simplifying installation and reducing the need for additional power sources.
Key Features
- HDMI 2.1 and HDCP 2.3 compliant
- Supports 40 Gbps FRL and 18 Gbps TMDS
- Delivers 8K @30fps (4:4:4) 10-bit and 4K @120Hz (4:4:4) 10-bit video
- Features VRR, FVA, and ALLM for enhanced video performance
- Pass-through support for HDR, HDR10, HDR10+, Dolby Vision, and HLG
- Extends video distribution up to 328 feet (100 meters)
- Supports e-ARC from receiver to transmitter
- USB 2.0 support with data rates up to 350 Mbps
- Bi-directional Ethernet (1Gb), analog audio, IR, and RS-232 pass-through
- Bi-directional PoC allows power from either transmitter or receiver
Technical Specifications
HDMI Compliance: HDMI 2.1
HDCP Compliance: HDCP 2.3
Video Bandwidth: 40 Gbps FRL, 18 Gbps TMDS
Video Resolution: Up to 8K @30fps (4:4:4) 10-bit, 4K @120Hz (4:4:4) 10-bit
HDR Support: HDR, HDR10, HDR10+, Dolby Vision, HLG
Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
Color Depth: 8/10/12-bit
Audio Formats: LPCM, Dolby Digital/Plus/EX, Dolby TrueHD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
IR Level: 12Vp-p
Transmission Distance: Up to 328 feet (100 meters) over CAT6A/7 cable
USB Compliance: USB 2.0 with data rates up to 350 Mbps
Ethernet: Bi-directional 1Gb
Power over Cable (PoC): Bi-directional, allowing power from either transmitter or receiver
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
Relative Humidity: 20% to 90% RH (non-condensing)
