Aurora IPX-TC1-F 4K over IPBaseT Transceiver, Fiber
The IPX-TC1 provides one of the most advanced IP Streaming solutions on the market utilizing Aurora’s IPBaseT technology, which synergizes various IP/AV standards to work together as one. It is the industry’s first 4K2K transceiver with zero compression and latency based on BlueRiver NT platform. Using a transmitter (encoder) and receiver (decoder), respectively, used to be the standard until now. The IPX-TC1 can be set up as either one to make installation, inventory, and troubleshooting easier.
Another industry first is the option slot to add other IP capabilities, like ExtremeUSB (USB 2.0 over IP) or Dante audio, for a more complete, distributed system.
Audio, video, data, and control can be sent securely to one or many units using off-the-shelf 10G Ethernet switches. When the IPX-TC1 is set up to be a transmitter, the 2 HDMI inputs become a source switch and the HDMI output becomes a potential loop out. When set up as a receiver, a user can select the local HDMI inputs or an IP source. Seamless switching of the sources further enhances the presentation. Regardless of how the IPX-TC1 is set up, the audio can be de-embedded at any location, break away, and/or be sent to or received from a Dante enabled device. The USB 2.0 option is also flexible, working as a KVM and/or a high-speed data transfer (480Mbps) for memory sticks. Each IPX-TC1 USB feature can also be set as a host or a device. To keep the system friendly, a customizable OSD and web server are available to be programmed as required. For RJ-45 LAN devices, the 1G Ethernet port allows full bandwidth end-to-end over the IPX-TC1 10G fiber or copper port. Control of the IPX system.
For 10G Fiber version: IPX-TC1-F
For 10G Copper version: IPX-TC1-C
Key Features
- Configure as Transmitter (Encoder) or Receiver (Decoder)
- 4K2K Over 10G Fiber or Copper
- Zero Compression & Zero Latency
- Secure Content Encryption
- 128x128 Capable with HDCP, Larger for Non-Encrypted Sources
- Videowall Capability with Zero Latency
- Seamless & Break-away Switching
- SFP+ for Multi/Single Mode Fiber
- 10/100/1000Mbps LAN
- 2 HDMI Inputs, 1 HDMI Output
- Line In/Out Stereo
- RS-232 Serial Port & IR (Bidirectional)
- User Configurable OSD
- Integrated Web Server for Custom Control Pages
- ExtremeUSB - USB 2.0 480Mbps Option (Host or Device Configurable)
- Dante IP Audio Option
- Front Keypad & IR Remote
- Auto Sense Switching
- Rack & Under Table Mounting
Technical Specifications
Compression
Zero
Latency
Zero
HDMI Inputs
2
HDMI Outputs
1
Audio Analog
3 Stereo Line In/Out (3.5mm TRS)
10G Ethernet
SFP+ (Single Mode or Multi-Mode) Fiber (IPX-TC1-F) or 10G copper (IPX-TC1-C)
LAN
RJ-45 10/100/1000M
Video bandwidth 340MHz
Video Support
Up to 4K2K 4:2:0 @60Hz
Audio Support
Up to 32 channels & Break-away Capable
RS-232
Up to 115k Baud (3.5mm TRS)
IR
20KHz-60KHz Front Panel
USB Connector
USB 2.0 Type A (Host or Device Software Selectable) with Option Card
Expansion Port
SO-DIMM for ExtermeUSB or Dante Options
Interface
IR or Keypad via OSD, Webserver
Connectors
Digital Video
(2) HDMI in with 3.5mm TRS audio, (1) HDMI Out with 3.5mm TRS audio
Data
(1) Ethernet port for network, (1) USB ports for charging & ExtremeUSB Option
Control
IR
20KHz-60KHz
Serial Up to 115K Baud
Physical & Power
Dimensions: 6.875"x4"x1.31" (175x102x33.3mm)
Weight: 2.58lbs
Power: 48VDC or PoE
