Effortlessly manage large-scale productions and live events with the JVC KM-IP12S8 12 NDI/SRT and 8 SDI Input 4K vMix Studio Switcher.

Switch seamlessly between 4K and high-capacity HD sources with 12 NDI/SRT and 8 SDI inputs, ensuring smooth visuals for your audience.

Enjoy silent and efficient operation thanks to the liquid-cooled housing, which keeps the system running smoothly even under demanding use.

Get up and running quickly with vMix 4K software pre-installed, a powerful tool for professional video production.

Key Features

• Broad compatibility with various input/output options including 12G-SDI, 3G-SDI, HDMI, and DisplayPort.

• Expand your workflow with a front dock for 4 x SSDs and USB 3.0 Gen.2 ports for digital audio and control surfaces (like the RM-LP350G Desktop vMix Control Surface).

• Work in peace with a quiet 4U case that uses liquid cooling to prevent overheating.

• Connect to multiple networks with three 2.5 GbE Ethernet ports for NDI, SRT, Dante, and RTMPS/Internet connectivity.

• Stream to multiple destinations simultaneously including three CDNs.

• Record isolated feeds of each source for editing or archival purposes with ISO recording.

• Capture highlights on the fly with the 1-channel Instant Replay feature.

Technical Specifications

12G SDI In/Out
4
HDSDI IN
4
Optional Inputs
NDI, SRT, RTSP, RTMP/VLC, UDP, H.264, H.265
IP Video stream input
12
NDI Input
12
HDSDI output
Yes
NDI output
Yes
HDMI output (PGM)
Yes
SDI/HDMI embeded Audio
Yes
USB Audio card support
Yes
Graphics DSK
4 x DSKs
ISO
ISO Recording of all inputs
Live Streaming
Yes
2160P (4K)
25p/29.97p/50p/59.94p
1080P
1080 25p/29.97p/50i/50p/59.94i/59.94p
720P
720 25/29.97/50/59.94p
Smart PTZ
Yes
Powered by Vmix
Yes
vMix Replay
Yes
Measurements (WxHxD) in Inches
W: 17 H: 7 D: 17
19" Rackmount
Yes
Rackmount Height in U
4 U
