JVC KM-IP8 8-NDI Input Studio Switcher
8-NDI Input Studio Switcher Powered By vMix
Key Features
- Minimum of 8-NDI inputs (up to 1080p60)
- vMix 4K licensed software
- 2RU
- 1x 3G-SDI Output
- 4x DisplayPort outputs
- 1x HDMI output
- Gigabit Ethernet Network Port
- Windows 11 Pro
- Includes standard keyboard and mouse
Technical Specifications
Network Video Input
Minimum of 8 IP video inputs (up to 1080p60) via NDI, SRT, RTSP, RTMP/VLC, UDP, H.264, H.265
3G-SDI Video Output
1x HD/SD-SDI + HDMI: Program output with embedded audio
HD 720 25/29.97/50/59.94p
HD 1080 25p/29.97p/50i/59.94i/59.94p
SD 480 50i/59.94i/25p/29.97p
Network Video Outputs
NDI, SRT, RTMP/S, H.264, H.265
Recording
ISO recording of all inputs
Storage
500GB SSD - system
500GB SSD - media and recording storage (recording time varies depending on number of media files stored on drive and recordings configuration)
Audio Input
3.5mm line in/microphone connector
HD/SD-SDI embedded audio
IP input embedded audio
USB 2.0/3.0 for AD converters and Audio Mixers
Dimensions (without rack ears)
16.8ā W x 15.0ā L x 3.5ā H
