Blackmagic Design ATEM 2 M/E Constellation 4K Ultra HD Live Production Switcher

The Blackmagic Design ATEM 2 M/E Constellation 4K Ultra HD Live Production Switcher is an unparalleled solution for professionals seeking to elevate their live production capabilities. This powerful 2 M/E switcher is designed to handle the most demanding production environments, delivering superior Ultra HD quality to ensure your broadcasts and live events are produced with utmost efficiency and precision. With an array of advanced features and high-end specifications, it stands out as a robust and versatile tool for any live production setup.

The ATEM 2 M/E Constellation 4K is equipped with 20 standards-converted 12G-SDI inputs and 12 12G-SDI aux outputs, providing immense flexibility for multiple video sources and outputs. The built-in 48-channel Fairlight audio mixer offers comprehensive audio management, ensuring pristine sound quality with EQ and dynamics processing. Featuring 8 ATEM Advanced Keyers, 2 Dynamic Video Effects (DVEs), and SuperSource with 6 DVEs, this production switcher enhances your creative workflow with seamless keying, transitions, and picture-in-picture compositions. Additionally, its USB webcam output enables straightforward streaming to popular platforms, making it an ideal choice for live streams, conferences, and more.

The ATEM 2 M/E Constellation 4K goes beyond traditional switchers by including built-in talkback, two multiviewers for monitoring multiple sources simultaneously, and support for various media formats through its media players. It also supports a plethora of HD and Ultra HD video standards, ensuring compatibility with diverse video formats and production requirements. Whether you are a broadcaster, live event producer, or content creator, this switcher offers reliability, versatility, and top-notch performance to meet your production needs.

Key Features

• Robust 2 M/E Ultra HD live production switcher.
• 20 standards-converted 12G-SDI inputs and 12 12G-SDI aux outputs.
• Built-in 48-channel Fairlight audio mixer with EQ and dynamics.
• 8 ATEM Advanced Keyers and 2 Dynamic Video Effects (DVEs).
• SuperSource offering 6 DVEs for versatile compositions.
• Two multiviewers for simultaneous source monitoring.
• USB webcam output for easy streaming to various platforms.
• Compatible with a wide range of HD and Ultra HD video standards.
• Built-in talkback for seamless communication.

Specifications

• Total Video Inputs: 20
• Total Video Outputs: 12
• SDI Rates: 1.5G, 3G, 6G, 12G
• Total Audio Inputs: 2 x balanced 1/4-inch Jack, 1 x 5 pin XLR Talkback.
• Total Audio Outputs: 1 x 5 pin XLR Talkback.
• SDI Audio Inputs: 16 Ch embedded audio on all SDI inputs.
• SDI Audio Outputs: 16 Ch embedded audio on all SDI outputs.
• Reference Input: Tri-Sync or Black Burst.
• Video Input Re-Sync: On all 20 inputs.
• Frame Rate and Format Converters: On all 20 inputs.
• SDI Aux Outputs: Any of the 12 SDI outputs.
• Webcam Output: 1 x USB-C supporting 720p or 1080p at PGM frame rate.
• Total Multi Views: 2 x 12G-SDI
• Control Panel Connection: Ethernet.
• Internal Timecode Generator: Yes
• Talkback: RJ45 for 3rd party talkback systems.
• Ethernet: Supports 10/100/1000 BASE-T.
• Computer Interface: 1 x USB-C supports USB 2.0
• Video Standards: Up to 2160p60
• Color Precision: 10-bit
• Color Space: REC 709, REC 2020
• Audio Mixer: 48 Channel with various dynamics and EQ
• Software Control: ATEM Software Control included for Mac and Windows.
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Power Supply: 1 x Internal 100 - 240 AC.
• Power Usage: 140 W
• Dimensions: 1 Rack Unit Size.

Package Contents

• ATEM 2 M/E Constellation 4K
• Welcome wallet with QR code for software download
• 12 Month Limited Manufacturer's Warranty
