ADDER INFINITY 1102T Single-Head Digital Video/Audio Over IP Network KVM Transmitter

ADDER INFINITY 1102T Single-Head Digital Video/Audio Over IP Network KVM Transmitter

The ADDERLink INFINITY 1102 is a high-performance IP KVM extender that allows for the relocation of critical computing hardware into a secure and temperature-controlled environment, away from the user workstation. This device ensures a pixel-perfect desktop experience, maintaining the integrity of the digital video and audio signals transmitted over a standard IP network. With its spatially-lossless encoding system, the ADDERLink INFINITY 1102 delivers color-accurate video without artifacts, making it ideal for professional environments where visual fidelity is paramount.

Designed for flexibility and scalability, the ADDERLink INFINITY 1102 can be configured as a simple extender or as part of a self-managed distributed KVM switch. It supports USB 2.0 devices, including graphics tablets and mass storage devices, while also providing options for network redundancy and unlimited extension distances. This makes it a versatile solution for various applications, from broadcasting to control rooms, where reliable and high-quality video and audio transmission is essential.

Key Features:

• Maximum Resolution: 2560 x 1600
• Frame Rate: 60 fps
• USB B: 1x 2.0 True Emulation, High Speed
• USB A: 1x 2.0 True Emulation
• Full Size DisplayPort: 1x
• 8p8c (RJ45): 1x
• SFP: 1x
• Serial Standard: RS232
• Maximum Baud Rate: 115,200
• Bandwidth: 1GbE
• Operating Temperature: 0 - 40 °C / 32 - 104 °F
• Storage Temperature: 0 - 40 °C / 32 - 104 °F
• Operating Humidity: 5% - 90% (non-condensing)
• Altitude: 2000m / 6561.68ft
• Mean Time Between Failure (MTBF): 476,000 h
• Power Supply: External Power Supply Unit
• Power Consumption: 12V 3-pin
• Construction Material: Robust metal construction
• Dimensions: 136mm x 39mm x 150mm
• Weight: 0.8kg / 1.76lb

Technical Specifications:

Category1: KVM Extender
Category2: IP Technology
Maximum Resolution: 2560 x 1600
Frame Rate: 60 fps
USB Support: 2.0 True Emulation
Operating Temperature: 0 - 40 °C / 32 - 104 °F
Weight: 0.8kg / 1.76lb
MTBF: 476,000 h

Package Contents:

• 1x ALIF1102 Transmitter
• 1x PSU-IEC-12VDC-1.5A: Mains power supply
• 1x IEC PSU cable of country code
• 1x VSCD18: 2m/6.5ft DisplayPort cable
• 1x VSC24: 2m/6.5ft USB cable
• 1x VSC22: 2m/6.5ft Audio cable
