Advanced Image Robotics AIR One Robotic Camera Kit and REMI Production Bundle

AIR One Robotic Camera Kit and REMI Production Bundle

The AIR One Bundle is a state-of-the-art production solution designed for filmmakers and content creators who demand precision, flexibility, and top-tier performance. This bundle includes everything you need to create cinematic footage with unmatched quality, including the powerful M4 Camera Module with a variety of advanced features. Whether you're shooting in 4K, 6K, or even 8K, the AIR One delivers exceptional video clarity and precision, equipped with a locking MFT lens mount and optional EF mounts. The system's intuitive interface makes it perfect for professional use, while the AIRstation enhances your workflow by providing advanced remote control capabilities and seamless connectivity options. With built-in stabilization and a robust construction made from aluminum alloy and carbon fiber, the AIR One Bundle ensures durability and smooth operation in any environment. Whether you're capturing a live event or shooting a cinematic scene, this bundle is ready to tackle all production challenges with ease.

The M4 Camera Module at the heart of the AIR One is equipped with a 4/3" WDR CMOS sensor, delivering stunning image quality and a dynamic range of 13 to 15 stops. This sensor allows for precise color reproduction and excellent performance even in low-light situations. The camera supports multiple recording resolutions, including 4K and 6K, offering filmmakers the flexibility to choose the right format for their project. It also features a powerful video encoder, capable of recording in ProRes Raw, ZRAW, H.264, and H.265 formats, giving you complete control over the post-production process. The AIR One Bundle also boasts a variety of lens options and an impressive frame rate range of up to 240 fps, ensuring smooth, high-quality footage for any application.

With a fully integrated gimbal system, the AIR One Bundle provides exceptional stabilization. The 3-axis gimbal, made from aluminum alloy and carbon fiber, offers full-time automatic stabilization and a payload capacity of up to 6.6 lbs (3 kg). The gimbal can rotate horizontally by 710º and vertically by 180º, providing flexibility in capturing any shot. Combined with the precision zoom and focus controls via the AIR iOS control app, the AIR One system guarantees smooth operation and exceptional shot composition in dynamic environments. Additionally, the AIR One Bundle's advanced streaming capabilities, such as RTMP and SRT, make it ideal for live broadcasts, allowing for secure, high-quality video streaming directly from your camera setup.

Key Features

• 4/3" WDR CMOS Sensor for exceptional image quality and dynamic range
• Resolution Options: 4K, 6K, and 8K recording capabilities
• Frame Rate Range: Up to 240 fps for high-speed footage
• Internal Recording: ProRes Raw, ZRAW, H.264, and H.265 formats
• Built-in Stabilization: 3-axis gimbal with automatic stabilization
• Streaming Support: RTMP and SRT for live streaming with AES encryption
• Lens Options: Locking MFT mount, optional EF lens mount
• Remote Control: Full control via AIR iOS app with low-latency remote operation
• Robust Construction: Aluminum alloy and carbon fiber for durability

Technical Specifications

Camera Modules

• M4 Camera Module
  • Sensor Type: 4/3" WDR CMOS Sensor (19.0 x 13.0 mm)
  • Effective Pixels: 10.28M
  • Dynamic Range: 13~15 Stops / 16 Stops with WDR
  • Lens Mount: Locking MFT (Optional: Locking EF, future PL)
  • Audio: Built-in Stereo Microphones, Aux Inputs: Lemo stereo/3.5mm stereo, 24-bit 48 kHz - AAC or PCM (MOV only), Gain -10 to +12, Noise Reduction on/off, Phantom Power on/off (lemo inputs only), Mic Level Only
  • Recording Resolution: 4096 x 2160 (C4K) / 3840 x 2160 (4K) / 1920 x 1080, 4096 x 1728 (C4K 2.4:1), 3840 x 1620 (4K 2.4:1), 3696 x 2772 / 3312 x 2760, 2704 x 1600
  • Frame Rate: 59.94 / 50 / 29.97 / 25 / 24 / 23.98 fps
  • Max Variable Frame Rate: 120 fps for 4096 x 2160 (H.265), 240 fps for 1920 x 1080 (H.265), 150 fps for 4096 x 1728 (H.265), 160 fps for 3840 x 1620 (H.265), 59.94 fps for 3696 x 2772
  • Max Bit Rate: H.265 / H.264, 300 Mbps for 4096x2160 / 3840x2160 / 4096x1728 / 3840x1620 / 3696x2772 / 3312x2760 / 2704x1600, 200 Mbps for 1920x1080
  • Color Bit Depth: 10-bit (H.265), 8-bit (H.264)
  • Video Encoder: 12-bit ProRes Raw / 12-bit ZRAW (partial debayer) / Proxy / H.265 main 10 profile / H.264 high profile
  • File Format: MOV / MP4
  • Internal Recording: C-Fast 2.0 exFAT
  • ISO: Auto, Manual (500 ~ 102400 / 250 ~ 51200 with WDR), Native ISO: 500 / 2500 (250 / 1250 with WDR)
  • Shutter Speed: Auto, Manual (up to 1/8000”)
  • Shutter Angle: Auto, Manual (1° ~ 360°)
  • White Balance: Auto, Preset, Manual (2300K ~ 7500K)
  • Focus Mode: MF / AF / CAF
  • Image Control: Brightness / Contrast / Saturation / Sharpness
  • Image Profile: Rec.709 / Z-Log2 / FLAT / HLG
  • Time Code: Time of Day / Manual Input
  • Streaming: SRT (end-to-end 128/256 bit AES encryption), RTMP, Bitrate 500kbs to 300Mbs, h.264/h.265, 1080p HD or 4K - fps: 24/25/30/60
  • Camera Material: Aluminum Alloy
  • Operation Temperature: 0ºC ~ 40ºC
  • Storage Temperature: -20ºC ~ 60ºC
• S6 Camera Module
  • Sensor Type: S35 sensor (23.4 x 15.67 mm) – 26M pixels – 14 stop DR
  • Resolutions and Frame Rates: 6244x4168 @30fps max (Open Gate), 6144x3240 @48fps max (6K DCI), 6144x2592 @60fps max (6K 2.4:1), etc.
  • ISO: 400~125000
• F6 Camera Module
  • Sensor Type: Full Frame 6K sensor – 37x24.75mm – 26M pixels – 15 stop DR
  • Resolutions and Frame Rates: 6064x4040 @30fps max (Open Gate), 6064x3196 @48fps max (6K DCI), 6064x2560 @60fps max (6K 2.4:1), etc.
  • ISO: 400~125000
• F8 Camera Module
  • Sensor Type: Full Frame 8K sensor - 36x24mm - 61M pixels - 14 stop DR
  • Resolutions and Frame Rates: 8192x3456 @30fps (8K 2.4:1), 7680x4320 @30fps (8K UHD), 6144x3240 @30fps max (6K DCI), etc.
  • ISO: 400~125000
• S6G Camera Module (Global Shutter)
  • Sensor Type: S35 – Global Shutter sensor – 28mm - 26M pixels - 14 stop DR
  • Resolutions and Frame Rates: 6144x4096 @30fps max (Open Gate), 6144x3240 @30fps max (6K DCI), 5760x3240 @30fps max (6K UHD), etc.
  • ISO: 1250~20000
