Aida UHD6G-200 Compact UHD 4K 6G-SDI EFP Broadcast Camera
Retaining the familiar form factor and durable design of the original AIDA GEN3G cameras, the UHD6G-200 brings the expanded control sets and increased video performance. The UHD6G-200 features an advanced 4K UHD Progressive Scan CMOS image sensor capable fo 4K (3840-2160) 6G-SDI output for Industrial and Broadcast applications realizing 4K video imaging with wide dynamic range. Designed for versatility with a user-interchangeable C to CS mount lens allows the UHD6G-200 to be used in nearly any kind of workflow.
Key Features
- 4K UHD 1/2.5 Progressive Scan CMOS sensor captures sharp and vivid UHD video even under very low light conditions
- Advanced digital imaging processor provides vivid and detailed images by utilizing Dynamic Range, Auto White Balance, and Noise Reduction
- Superb motion-compensated temporal noise reduction lter for motion video without blurring
- OSD control breakout cable with audio input and RS-485 for remote communication
- Flawlessly relays multi-channel embedded audio via SDI
- Interchangeable lens design compatible with CS and C mount lenses
- Perfectly suited for broadcast, pro audio/video, and security
- Conforming with SMPTE 292M, 424M and 2081-10
- Versatile, compact, and rugged design
Technical Specifications
Video
Image Sensor
1/2.5" Progressive CMOS
Sensor Size
8.365mm X 6.615mm (16:9)
Effective Pixels
Horizontal: 3840, Vertical: 2160
Pixel Size
1.62 m (H) x 1.62 m (V)
Resolution
3840 x 2160, 1920 x 1080, 1280 x 720
Resolution/Rate
2160p 30/29.97/25/24
1080p 60/59.94/50/30/29.97/25/24
1080i 60/59.94/50
720p 60/59.94/50/30/25
Output
HD/3G/6G-SDI (BNC)
Color Space
4:2:2 (YCbCr) 10bit
Function
White Balance
AWB / AE / AF
Exposure
Full Auto, Bright, Shutter Priority, Iris Priority, Manual
Others
WDR, DIS (Digital Image Stabilization), 2D/3D Noise Reduction,
Digital Slow Shutter, Black Level Compensation, Flicker Detection
Lens
Lens
C/CS Mount
Audio
Input
3.5mm Analog Audio Jack over I/O Cable
Sample Rate
16/24/32 Bits
Standard
SMPTE
SMPTE 292M, SMPTE 424M, SMPTE 2081-10
Physical
Camera Control
RS-485
OSD Button
Operation Temp
15F - 120F
Dimension
49m x 49mm x 71mm / 1.92" x 1.92" x 2.79"
Weight
170g / 0.37 lbs
Power
12VDC (+9 - +15VDC)
