Altronix Tempo724Q Two Channel Networked Annual Event Timer

Altronix Tempo724Q Two Channel Networked Annual Event Timer

The Altronix Tempo724Q is a highly versatile two-channel networked annual event timer engineered for security, access control, lighting control, and building automation. Compact yet powerful, it provides users with reliable scheduling for latching or momentary relay events and integrates seamlessly with professional systems. The device features embedded LINQ™ Network Management Technology, enabling remote programming, diagnostics, and email or dashboard alerts for maximum convenience and control.

Equipped with two independently controlled relays, the Tempo724Q supports up to 60 programmed daily or weekly events and 420 total block events per week. It also allows for 30 programmable holiday dates and includes an accurate, crystal-controlled clock with automatic leap year adjustments. Designed with flash memory, the unit ensures event programming is preserved in the event of a power failure, guaranteeing reliability in critical environments.

With its compact board size, efficient power options, and lifetime warranty, the Altronix Tempo724Q delivers unmatched scheduling flexibility, professional-grade reliability, and remote accessibility. It is the ideal choice for integrators and end users seeking dependable automation and event scheduling.

Key Features

• Two independently controlled Form “C” relays rated 5A at 24VDC/120VAC
• Supports up to 60 daily/weekly events, 420 weekly block events, and 30 holiday dates
• Embedded LINQ™ technology for remote programming, user management, and diagnostics
• Flash memory ensures schedules are preserved during power loss
• Crystal-controlled clock for precise and accurate timekeeping
• Daylight Savings and leap year automatic adjustments
• Email and dashboard alerts for real-time system status
• Includes mounting hardware and backed by a lifetime warranty

Technical Specifications

• Input Voltage: 12VDC/24VDC or PoE (12.95W, Class 3)
• Aux Power Output: 12V 100mA, 24V 80mA
• Standby Current: 10mA (relay off) / 50mA (relay on)
• Relay Contact Rating: Form “C” 5A 24VDC/120VAC
• Event Scheduling: 60 daily/weekly events, 420 block events, 30 holidays
• Battery Charging: 0.25A; supports sealed lead acid or gel type
• Board Dimensions: 5.5 in × 3.5 in × 1 in
• Shipping Dimensions: 8 in × 6 in × 5 in
• Weight: 0.48 lb (product) / 0.5 lb (shipping)
• Operating Temperature: –4 °F to 120 °F (–20 °C to 49 °C)
• Storage Temperature: –13 °F to 158 °F (–25 °C to 70 °C)
• Relative Humidity: 85% ± 5%
