Condition: New
Palmer GA 04 L0 4 Speaker Simulator with Loadbox, 4 Ohms
Special DI box with load box for guitars. The integrated load resistor permits tube amplifiers up to approximately 120 W to be connected to the PGA04, bypassing a loudspeaker. A jack socket (unbalanced) and balanced XLR connector are available for direct pickup of the signal. The extensive filter section provides for a realistic simulation of classic guitar loudspeaker sounds.
Technical Specifications
Product type
Speaker Simulators
Channels
1
Input type
unbalanced
Inputs
1
Input connectors
6.3 mm jack
Output type
balanced , unbalanced
Outputs
2
Output connectors
6.3 mm jack , XLR
Output impedance
10 k (6.3 mm Jack) Ohm(s) , 600 (XLR) Ohm(s)
Controls
color , filter volume , full range volume , high , high cut , low
Indicators
max. load
Dummy load
Yes
Dummy load impedance
4 Ohm(s)
Max. load
100 W
Voicing filter
Yes
Power attenuator
no
transformer balanced inputs
no
Transformer isolated outputs
Yes
Cabinet material
sheet steel
Cabinet surface
Powder coated
Width
480 mm
Width
19”
Depth
180 mm
Height
44.5 mm
Height
1 U
Weight
2,56 kg
