Arturia AudioFuse 16Rig 16-Channel Audo and MIDI Interface

Arturia AudioFuse 16Rig 16-Channel Audo and MIDI Interface

Arturia’s AudioFuse 16Rig is a professional interface that combines massive connectivity with flexible configurations for connecting an entire synth studio, complex live audio routing, advanced DAW recording, and beyond. And, like the rest of Arturia’s line-up, it does all this in an intuitive, workflow-focused way that encourages creativity & experimentation.

With 16 analog inputs, 12 analog outputs, dual-ADAT I/O ports with Word Clock sync, low latency DSP mixers, standalone audio and MIDI functionality and much more, AudioFuse 16Rig raises the bar in the audio interface category. It gives users an unmatched package of technical power, creative features, and maximum flexibility at an unbeatable price.

Ultimate studio centerpiece
Studio full of synths? Full band recordings? Complex monitor & send/return routing? AudioFuse 16Rig’s next-level connectivity and versatility meets the most demanding needs of today’s producers; an entire setup can be kept connected to the rear I/O, leaving the front panel connections available for additional mics, instruments, or devices.

Pristine audio quality
AudioFuse 16Rig gives recordings the shine and clarity they deserve with premium 24-bit AD/DA converters from ESS and Cirrus Logic. Whether it’s synths, guitars, vocals, or any combination of inputs, expect consistent top-tier sound.

A standalone mixer
For DAWless recording, live mixing, and computer-free audio configuration, AudioFuse 16Rig just works. The interface can process audio & MIDI signals even without a computer connected, and comes with a low-latency internal mixer that can be easily controlled via MIDI. Better still, many of the essential recording and mixing controls can be configured, saved, and recalled via the device itself for quick setup switching.

Intricate audio routing
AudioFuse 16Rig goes far beyond ins and outs. Configure its connections to suit any need, including multiple sends/returns, A/B speaker monitoring, and more. The included AudioFuse Control Center even features a matrix for quick ‘connect anything and everything’ configuration.

Choose your workflow
AudioFuse 16Rig can be set up to suit any workflow. Users can control its settings via the built-in controls or the included software, configure it for desktop or rackmount operation, use the DC-coupled outputs to send signals to synth modules, and even connect high-impedance headphones.

Key Features

• High-density audio inputs - 16 TRS analog inputs, 2 combo Inst/XLR inputs with high quality digitally
  recallable preamps, and even a convenient 3.5mm stereo input for easy connection of compact devices.
• Flexible outputs & monitoring - 12 analog outputs, including 8 DC-coupled TRS line outputs, front panel
  outputs for reamping or dual-headphone configuration, speaker outputs, and both 6.35mm and 3.5mm TRS headphone connections.
• ADAT with Word Clock - Add up to 16 channels of input and output at 48kHz via ADAT, complete with Word Clock for precise synchronization between devices.
• Standalone MIDI - Connect MIDI gear with USB or 5-pin DIN connectors and route signals with ease, even without a computer connected.
• A USB mastermind - Class-compliant MIDI hosting, low-latency USB-C connection to computer, additional front & back USB hub ports.
• Color display - Detailed real-time feedback on levels, routing, settings, and more.
  Desktop or rackmount - Configurable for accessible desktop use or a tidy rackmount attachment to suit any setup.
• AudioFuse Creative Suit - A suite of premium software including Analog Lab Intro and Arturia FX plugins.

Technical Specifications

16 x TRS analog inputs
Includes 2 x high-quality digitally-controlled preamps
Inputs 3 & 4 also available as 3.5mm stereo input
12 x analog outputs
Includes 8 x DC-coupled TRS line outputs
Stereo monitor outputs
6.35mm front-panel outputs for reamping, dual-headphones
2 x ADAT in, 2 x ADAT out
Up to 16 channels of I/O at 48kHz, 8 channels at 88.2/96kHz
1 x MIDI in, 2 x MIDI out/thru
5-pin DIN connectors
Route MIDI standalone
Low-latency USB-C connection
Class-compliant MIDI
3 x USB hub connections
Two internal standalone mixers
No computer connection needed
Features
Cue mixer for sub-mixing and added flexibility
Main mixer controllable by MIDI
Color display with rotary control & menu buttons
Desktop or 1U rackmount configuration
Includes AudioFuse Control Center
Includes AudioFuse Creative Suite
-Analog Lab Intro
-Comp DIODE-609* NEW
-Pre 1973
-Pre V76
-Pre TridA
-Filter MINI
-Chorus JUN-6
-Comp FET-76
-Delay TAPE-201
-Rev PLATE-140
-Phaser BI-TRON
What's in the box
AudioFuse 16Rig unit
Power supply
2x USB cable
Instrument dimensions
17.3 x 11.6 x 1.7 inches (493 x 294 x 43mm)
Platform requirements
Windows
Win 10+ PC: 4 GB RAM; Intel i5 CPU or faster
1GB free hard disk space
OpenGL 2.0 compatible GPU

Apple
10.13+: 4 GB RAM; Intel i5 CPU or faster
1GB free hard disk space
OpenGL 2.0 compatible GPU
