The Ashly FX750.2 3,000W 2-Channel DSP Power Amplifier represents a cutting-edge fusion of amplification and digital signal processing, redefining the standards for audio performance and versatility. At its core lies a sophisticated DSP engine, meticulously engineered to provide unparalleled control over audio signal manipulation. Users can effortlessly sculpt the sound to perfection, from subtle tonal adjustments to intricate equalization curves, ensuring an optimal listening experience across a wide range of applications. The FX Series' ability to seamlessly transition between low and high impedance modes underscores its adaptability, allowing for integration into diverse audio systems without compromise.

Beyond its sonic prowess, the FX Series prioritizes user experience through intuitive operation and advanced connectivity. The amplifier's user-friendly interface, coupled with wireless and wired networking capabilities, empowers users to effortlessly manage and monitor their audio systems. Whether fine-tuning settings from a desktop or mobile device, users enjoy unparalleled control and flexibility. The FX Series' compact footprint and efficient power delivery further enhance its appeal, making it an ideal choice for space-constrained installations while delivering exceptional performance.

The Ashly FX Series is more than just an amplifier; it is a comprehensive audio solution designed to meet the demands of modern audio professionals and enthusiasts. With its robust construction, reliable performance, and advanced feature set, the FX Series delivers exceptional value. Whether powering critical commercial installations, enhancing residential entertainment systems, or supporting professional audio production, the FX Series consistently exceeds expectations, setting new benchmarks for audio excellence.

The FX Series' versatility extends beyond its technical capabilities. Its ability to seamlessly integrate into various audio environments makes it a preferred choice for a wide range of applications. From small-scale installations to large-scale projects, the FX Series delivers consistent performance and reliability. Whether powering background music in retail establishments, providing clear and intelligible audio in corporate conference rooms, or delivering immersive sound experiences in entertainment venues, the FX Series excels, ensuring optimal audio quality in every scenario.

In conclusion, the Ashly FX Series represents a groundbreaking advancement in amplifier technology. By combining powerful amplification with sophisticated DSP, the FX Series delivers unparalleled audio performance, flexibility, and user-friendliness. Its ability to adapt to diverse audio environments, coupled with its robust construction and advanced features, solidifies its position as a leading choice for audio professionals and enthusiasts seeking exceptional sound quality and reliable performance.

Key Features

• High power density options available

• 60W x 2 Ch or 4 Ch, 125W x 2 Ch or 4 Ch in ½ RU chassis

• 500W x 2Ch or 4 Ch in 2 RU chassis

• Selectable low (4/8 Ohm) or Hi Impedance (70/100V) operation

• Balanced Mic/Line inputs on removable Euroblock connectors, plus unbalanced RCA inputs

• 2-channel SPDIF Digital IO

• Front panel status LEDs for amp, Input, output & network

• Networkable via Ethernet or built-in WiFi

• Built-in advanced DSP on all inputs & outputs

• Browser-based UI accessed via PC or mobile device

• 4 Input channels x 2 or 4 Output channels for all models

• Auto/Manual Power Saver Mode (sleep/standby), adjustable in Software

• Customized Speaker Presets made be created, saved & loaded for each output channel

• Addressable GPIO, Standby/Mute & VC remote ports

• ½ RU models easy to hide in “non-rack” installations

• Highly efficient Class D and lightweight

• Optional hardware for ½ RU models for rack & wall/surface mounting

Technical Specifications

Channels
FX 750.2: 2 x Lo-Z /1 x Hi-Z
FX 750.4:
Output power @ 4Ω/8Ω
FX 750.2:
@ 2Ω 2 x 750W (SE)
@4Ω 2 x 750W (SE), 1 x 1500W (BTL)
@ 8Ω 2 x 375W (SE), 1 x 1500W (BTL)
FX 750.4:
@ 2Ω 4 x 750W (SE)
@4Ω 4 x 750W (SE), 1 x 1500W (BTL)
@ 8Ω 4 x 375W (SE), 1 x 1500W (BTL)
Output power @ 25V
FX 750.2: 2x 320W
FX 750.4: 4x 320W
Output power@ 70V/100V*
FX 750.2: 1X 1500W (BTL)
FX 750.4: 2X 1500W (BTL)
Total System Power
FX 750.2: 3000W
FX 750.4: 3000W
DSP
4 Input x 2 or 4 Outputs: Input, Zone, Output & Speaker Processing, plus General settings
Networking
Browser-based UI Software with Ethernet & WiFi connectivity
Power Consumption
FX 750.2: 550W
FX 750.4: 1100W
Dimensions
89 x 482.5 x 320 mm (19 in x 3.5 in x 12.6 in)
Weight
FX 750.2: 6 kg (13.3 lbs)
FX 750.4: 7.5 kg (16.5 lbs)
Output Circuitry
Class D - full bandwidth PWM modulator with ultra-low distortion
Output Voltage
85 Vp / 170 Vpp (unloaded) / Bridged 170 Vp / 340 Vpp (unloaded)
Signal To Noise-Ratio
> 108 dB (A-weighted, 20 Hz - 20 kHz, 8Ω load)
THD +N (typical)
< 0.05% (20 Hz- 20 kHz, 8 Ω load, 3 dB below rated power)
Frequency Response
20 Hz - 20 kHz (+/ - 0.5 dB, 8 Ω load, 3 dB below rated power)
Protection Circuits
Short circuit, DC, Undervoltage, Temperature - and Overload protection
Power Supply
Universal mains switch mode power supply with Power Factor Correction (PFC) and standby converter
Operating temperature
0-40 C
Operating Voltage/Frequency
Universal Mains, 100V - 240V, 50Hz- 60Hz
Standby Consumption
< 0.5 W
Accessories
Rack Ears (Included)
Power Ratings
1% THD @ 120 Vac and 230 Vac
