ATEN CL6700MW Single Rail LCD Console, USB, HDMI/DVI /VGA

The CL6700 features an integrated 17.3" (CL6700MW) or 19” (CL6700N) LED-backlit LCD panel, a full keyboard, and a touchpad in a 1U rack-mountable sliding housing with audio support. The CL6700 LCD KVM console provides front end access to compatible KVM switches utilizing space with a module that closes flat and slides into the rack. The CL6700MW supports three types of video input - HDMI, DVI, and VGA - and provides the ultimate in installation flexibility by allowing users to connect the console and the computer via any of the three types of video source. For added convenience, the 17.3" full HD console features a port for an external USB mouse on the unit’s front panel, while ports for the second KVM console (USB keyboard, USB mouse and HDMI, DVI, or VGA monitor) are provided on the rear panel.

Key Features

• Exclusive LED illumination light - designed by ATEN to illuminate the keyboard and touchpad to allow visibility in low-light conditions
• Integrated KVM console with a 17.3'' LED-backlit Widescreen Full HD LCD monitor in a single rail housing with top and bottom clearance for smooth operation in a 1U high system rack (CL6700MW)
• Integrated KVM console with a 19" DVI LCD monitor in a single rail housing with top and bottom clearance for smooth operation in a 1U high system rack (CL6700N)
• Superior video quality - up to 1920 x 1080 @ 60Hz (CL6700MW); up to 1280 x 1024 @75 Hz (CL6700N)
• Supports an external console with USB / DVI / VGA / HDMI connectors (CL6700MW); supports an external console with USB / DVI / VGA connectors (CL6700N)
• Additional hot-pluggable USB mouse port on front panel (also functions as USB peripheral port)
• Audio support (speakers)
• Standard rack mount kit included
• Optional rack mount kits available including easy installation options
• Standard 105-key keyboard; Sun keyboard emulation
• Multiplatform support - Windows, Linux, Mac, and Sun
• Firmware upgradeable
• Console lock - enables the console drawer to remain securely locked away in position when not in use
• DDC emulation - video settings of each computer are automatically adjusted for optimal output to the monitor
• Keyboard Language support: English(US); English(UK); German; German(Swiss); French; Spanish; Traditional Chinese; Japanese; Korean; Swedish; Italian; Russian; Hungarian; Greek
