ATEN CS64US 4-Port USB VGA/Audio Cable KVM Switch, 0.9 Meters, 1.2 Meters

ATEN CS64US 4-Port USB VGA/Audio Cable KVM Switch, 0.9 Meters, 1.2 Meters

The CS64US takes a giant step forward from prior cable KVM models in the Petite series, by offering built-in cables, USB peripheral sharing, and a firmware upgrade function that allows you to keep up with latest available versions.

Furthermore, the CS64US features enhanced Video DynaSync technology, which stores the console monitor's EDID (Extended Display Identification Data) to optimize display resolution. The CS64US also offers multiplatform support and computer selection via hotkeys to provide the ultimate in desktop convenience.

Key Features

• One USB console controls four USB computers
• Compact design, built-in 0.9/1.2 m cables
• Hotkey selection for OS and keyboard language
• Computer Selection via hotkey
• Multiplatform support - Windows, Linux, Mac, Sun
• Video DynaSync - exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
• USB mouse port can be used for USB 1.1 hub and USB 1.1 peripheral sharing
• Supports multifunction and wireless keyboards and mice
• All-in-one design
• With speaker support
• Superior video quality - up to 2048 x 1536; DDC2B
• Auto Scan function to monitor computer operation
• Bus-Powered
• Sun/Mac keyboard support and emulation*
• Firmware upgradable

Technical Specifications

Computer Connections
4
Port Selection
Hotkey
Connectors
Console Ports
1 x HDB-15 Female (Blue)
2 x USB Type A Female
1 x 3.5mm Audio Jack Female (Green)
KVM Ports
4 x HDB-15 Male (Blue)
4 x USB Type A Male
4 x 3.5mm Audio Jack Male (Green)
LEDs
Selected
4 (Green)
Cable Length
Computer
2 x 0.9 m; 2 x 1.2 m
Emulation
Keyboard / Mouse
USB
Video
2048 x 1536; DDC2B
Scan Interval
1-99 secs. (Default 5 secs.)
Power Consumption
DC5V:0. 9W:8BTU
Environmental
Operating Temperature
0 - 50°C
Storage Temperature
-20 - 60°C
Humidity
0-80% RH, Non-condensing
Physical Properties
Housing
Plastic
Weight
0.58 kg (1.28 lb)
Dimensions (L x W x H)
9.41 x 9.72 x 2.60 cm
(3.7 x 3.83 x 1.02 in.)
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
