ATEN VE882 HD Video Audio Optic Fiber Extender up to 1980 Feet

ATEN VE882 HD Video Audio Optic Fiber Extender up to 1980 Feet

The VE882 is an Optical HDMI Extender that overcomes the length restriction of standard HDMI cables by using optical fiber to send high definition audio and video signals over large distances.

The VE882 accepts an audio-video stream from a local source and serializes the data to pass it over a single 3.125 Gbps optical link (for resolutions up to 1080p@60Hz at 24-bits).

The VE882 can also extend the IR remote control and transfer RS-232 (up to 115kbps) in both directions, allows you to connect serial devices such as touch screens and barcode scanners.

Key Features

• Extends the transmission range of HDMI, IR and RS-232 signals using one fiber optic cable
• Very long distance transmission up to 1970 ft. (600m)
• HDMI (3D, Deep Color), HDCP compatible signaling rates up to 3.125 Gbits
• Superior video quality up to 1080p@60Hz
• Supports full frequency IR signal from 30KHz to 60KHz
• Uses one fiber optic cable to connect the local and remote units
• Supports wide screen formats
• Built-in 8KV/15KV ESD protection
• Features RS-232 serial port for connecting peripherals such as touch screens, barcode scanners, etc.
• Supports bi-directional IR signal transmission, one way at a time
• Rack-mountable
• Hot-pluggable

Technical Specifications

VE882T
Power Consumption: DC5.3V, 5.6W
Operating Temp. : 0-50°C
Storage Temp. : -20-60°C
Humidity: 0-80% RH, Non-condensing
Housing: Metal
Weight: 0.9 lb. (0.42 kg)
Dimensions (L x W x H): 5.6 x 4.1 x 1.2 in. (14.17 x 10.30 x 3.12 cm)

VE882R
Power Consumption: DC 5.3V 5.1W
Operating Temp. : 0-50°C
Storage Temp. : -20-60°C
Humidity: 0-80% RH, Non-condensing
Housing: Metal
Weight: 0.9 lb. (0.42 kg)
Dimensions (L x W x H): 5.6 x 4.1 x 1.2 in. (14.17 x 10.30 x 3.12 cm)
