Aten VE901 | DisplayPort HDBaseT Lite Extender
Aten VE901 | DisplayPort HDBaseT Lite Extender
Free Shipping
Aten VE901 DisplayPort HDBaseT Lite Extender
The VE901 DisplayPort HDBaseT-Lite Extender is able to extend a DisplayPort display up to 70 m using a Cat 6 / 6a cable. This combination of ATEN and HDBaseT technology supports sharing 4K media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
Key Features
- HDBaseT Connectivity extends a DisplayPort connection up to 70 meters via a single Cat 6/6a cable
- HDBaseT Anti-Jamming resists signal interference during video transmission using HDBaseT technology
- Featuring 3.3V / 500mA power output for powering auxiliary devices
- Rack-Mountable
- 2x Power Adapters
Technical Specifications
Video Input
VE901R
Interfaces
N/A
Impedance
N/A
Max. Distance
N/A
Video Output
Interfaces
1 x DisplayPort Female (Black)
Impedance
100
Video
Max. Data Rate
10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock
340 MHz
Compliance
DisplayPort (Deep Color, 4K)
HDCP Compatible
Max. Resolutions / Distance
Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a);
1080p@60m (Cat 5e/6) / 70m (Cat 6a)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio
Input
N/A
Output
1 x DisplayPort Female (Black)
Power
Connectors
1 x DC Jack (Black) with locking
Consumption
DC 5V, 7.95W
Environmental
Operating Temperature
0-40°C
Storage Temperature
-20 - 60°C
Humidity
0 - 80% RH, Non-Condensing
Physical Properties
Housing
Metal
Weight
0.27 kg ( 0.59 lb )
Dimensions (L x W x H)
10.06 x 8.70 x 3.00 cm
(3.96 x 3.43 x 1.18 in.)
VE901T
Interfaces
1 x DisplayPort Female (Black)
Impedance
100
Max. Distance
1.5 m
Video
Max. Data Rate
10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock
340 MHz
Compliance
DisplayPort (Deep Color, 4K)
HDCP Compatible
Max. Resolutions / Distance
Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a);
1080p@60m (Cat 5e/6) / 70m (Cat 6a)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio
Input
1 x DisplayPort Female (Black)
Power
Connectors
1 x DC Jack (Black) with locking
Consumption
DC 5V, 3.13W
Environmental
Operating Temperature
0-40°C
Storage Temperature
-20 - 60°C
Humidity
0 - 80% RH, Non-Condensing
Physical Properties
Housing
Metal
Weight
0.24 kg ( 0.53 lb )
Dimensions (L x W x H)
10.06 x 8.70 x 3.00 cm
(3.96 x 3.43 x 1.18 in.)
