ATEN VS194 4-Port 4K DisplayPort Splitter
The VS194 4-Port 4K DisplayPort Splitter is the perfect solution for anyone who needs to send one source of DisplayPort high definition video to two or four DisplayPort displays. The VS194 can not only split but also expand DisplayPort audio/video signal on two or four DisplayPort monitors which is ideal for any multi-display application.
Key Features
- Connects one DisplayPort source to two or four DisplayPort monitors
- Supports DisplayPort 1.2a; HDCP 1.3
- Supports resolutions up to 4096 x 2160 / 3840 x 2160 @ 60 Hz
- Supports MST/ Extend Mode and SST/ Split Mode*
- Supports Linkrate: HBR2 (High Bit Rate 2)
- Note: * The VS192/VS194 will bypass EDID Mode during SST Mode and will detect the resolution of the monitor connected to port 1
Technical Specifications
Video Output
Interfaces
4 x DisplayPort Female (Black)
Video Input
Interfaces
1 x DisplayPort Female (Black)
Video
Compliance
DP 1.2a; HDCP 1.3
Max. Resolution
Up to 4096 x 2160 / 3840 x 2160 @ 60Hz
Max. Data Rate
21.6 Gbps (5.4 Gbps per lane)
Connectors
Power
1 x DC Jack
Power Consumption
5 VDC, 3.36W
Environmental
Operating Temperature
0-40 C
Storage Temperature
-20 - 60 C
Humidity
0 - 80% RH, Non-Condensing
Physical Properties
Housing
Metal
Weight
0.33 kg ( 0.73 lb )
Dimensions (L x W x H)
12.50 x 8.00 x 2.50 cm (4.92 x 3.15 x 0.98 in.)
Carton Lot
20 pcs
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
