Atlas Sound TSD-ALC2 Audio Level Controller/Limiter
Atlas Sound TSD-ALC2 Audio Level Controller/Limiter
Free Shipping
Atlas Sound TSD-ALC2 Audio Level Controller/Limiter
The AtlasIED TSD-ALC2 is an automatic 2-channel audio level controller/limiter that allows designers and installers the ability to set predetermined maximum source levels. The TSD-ALC2 is great for installations with multiple program sources including satellite receivers, mp3 players, etc. that typically have vast output level irregularities. With the TSD-ALC2 inserted in line with these sources, the audience will not be distracted during high volume commercial breaks or when different inputs are selected. Retail stores, restaurants, sports bars, hotels, event centers, and other facilities can all benefit from improved sound when the TSD-ALC2 is integrated.
Key Features
- Stereo Auto Level Control
- Unbalanced RCA Input and Output
- Threshold Level Adjustment
- Ramp Speed Selection
- Output Gain Control
- Security Covers Included for All Front Panel Controls
- Energy Efficient
- Compact Chassis Design
- Power Supply Sold Separately
Technical Specifications
Input Type
(2) Unbalanced, RCA, Left & Right
Output impedance
150 Unbalanced
Output Level
Adjustable from 0V - 1.4V, Hard Limit
Input Level Attenuator
(1) Removable Knob w/ Security Cover
Indicators
Input:Green, Input Peak:Red, ALC Active:Yellow, Power:Blue
Power Consumption
1.4 Watts
Chassis Material
Aluminum
Chassis Color
Black
Height
1.5" (39mm)
Depth
2.75" (70mm)
