AtlasIED 744-30 Heavy‑Duty Floor Rack Cabinet with 20-Inch Depth, 44RU
The AtlasIED 744‑30 is a premium, heavy-duty floor rack cabinet designed for professional AV, IT, broadcast, and data installations that demand depth and durability. Built with a robust 14-gauge cold-rolled steel frame and reinforced with welded 11-gauge caster gussets, this 44 RU cabinet supports serious equipment loads with ease. Its interlocking, multi-formed frame construction ensures maximum strength and rigidity, ideal for single or multi-bay configuration.
Measuring 81.25″ high, 22.31″ wide, and 30″ deep (usable depth: 28.03″), the 744‑30 provides extensive vertical and rear equipment space while maintaining a standard footprint. The solid, vent-free enclosure facilitates precise thermal management and protection against contaminants. The cabinet ships with two pairs of fully adjustable, plated 11-gauge rack rails tapped 10‑32 (with RU indicators), two 3‑RU blank panels, and includes base-leveling sockets with caster-ready gussets—and can be permanently anchored to the floor for enhanced stability.
Key Features
- Heavy-Duty Construction: Welded 14‑gauge CRS frame with 11‑gauge caster gusset reinforcement
- 44 RU Capacity: Ample room for high-density rackmount systems
- 30″ Depth: Offers a usable depth of 28.03″ to accommodate deep equipment
- Adjustable Rack Rails: Two sets of 11‑gauge CRS rails, tapped 10‑32 with RU markings
- Solid, Vent-Free Design: Enables custom airflow control and prevents debris ingress
- Flexible Base Options: Threaded leveling sockets, caster-ready gussets, or floor anchoring
- Optional Seismic Kit: Compatible with SBK‑700 for NEBS Zone 4 compliance
- UL Listed: Certified to UL 1678 safety standard for industrial rack environments
Technical Specifications
- Rack Units: 44 RU
- Height: 81.25″ (206.4 cm)
- Width: 22.31″ (56.7 cm)
- Depth: 30″ (76.2 cm)
- Usable Depth: 28.03″ (71.2 cm)
- Frame Material: 14‑gauge cold-rolled steel
- Caster Gussets: Reinforced 11‑gauge steel corners
- Rail Spacing: EIA standard, rails recessed 1 3/16″ with 10‑32 taps
- Safety Listing: UL 1678 certified
What’s Included
- AtlasIED 744‑30 Floor Rack Cabinet (44 RU, 30″ depth)
- Two pairs of adjustable 11‑gauge CRS rack rails (10‑32 tapped with RU marks)
- Two 3‑RU blank panels (5.25″ total)
- Base assembly with caster-ready gussets and threaded leveling sockets
- Top panel with provisions for cable or optional fan integration
