AtlasIED AWR2W Tilt-Out Wall Cabinets for 19-Inch Equipment, 2RU
The AtlasIED AWR2W is a versatile 2RU tilt-out wall cabinet designed for mounting 19-inch equipment with convenient access and secure lock-in features. It can be surface or recessed mounted, complete with a trim ring for recessed installation. The cabinet includes a 3RU panel opening above the main bay for connector panels or power distribution. Its compact design is ideal for housing remote amplifiers and control equipment, with a usable depth of 17 1/4-Inch for the bottom RU and 20-Inch for the top RU.
Constructed with a 16-gauge CRS formed door frame and locking tilt-out door, the cabinet ensures tamper-resistant security. The door features two pin-style hinges for internal attachment and opens to two positions: tilt-out for operation and a 90-Degree swing for easy equipment installation and maintenance, supported by steel safety catch cables. The front panels boast clean 45-degree mitered edges for a flush and professional appearance, while the back box includes six concentric knockouts for cable routing.
Key Features
- 2RU tilt-out wall cabinet for 19-inch equipment
- Surface or recessed mounting with included trim ring
- 3RU panel opening above main bay for connector panels or power distribution
- Locking door with tamper-resistant pin-style hinges
- Doors open to tilt-out position and 90-Degree for maintenance
- Steel safety catch cables hold doors at 90-Degree
- 16-gauge CRS construction with clean 45-degree mitered edges
- Back box with six 1/2-Inch and 3/4-Inch knockouts for wiring
Technical Specifications
- Rack Units: 2
- Height: 34-Inch (86.36 cm)
- Width: 27-Inch (68.58 cm)
- Depth: 4 3/4-Inch (12.192 cm)
- Usable Depth: 17 1/4-Inch (43.815 cm)
- Shipping Weight: 54.00 lbs (24.49 kgs)
- Warranty Period: 60 months from date of purchase
