AtlasIED DD87W-HC 8-Inch In-Ceiling Coaxial Speaker with 70.7V 8W Transformer, Baffle, and Hyfidrophobic Treatment Coating
Free Shipping
More finance options:
Estimated Shipping Widget will be displayed here!
Most orders placed before 10:00am PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
AtlasIED DD87W-HC 8-Inch In-Ceiling Coaxial Speaker with 70.7V 8W Transformer, Baffle, and Hyfidrophobic Treatment Coating
The DD87W-HC delivers high-performance audio in a sleek, in‑ceiling design engineered for seamless integration into existing systems. Featuring a full-size 8‑Inch low‑frequency woofer and 3‑Inch high‑frequency tweeter with a built‑in crossover, it replicates the famed sonic signature of the AtlasIED C803A. With a broad 105‑Degree dispersion, wide frequency response, and 96 dB sensitivity, this speaker ensures clear, balanced sound coverage throughout any space.
Designed for flexibility, the DD87W-HC is equipped with a premium 8‑watt transformer compatible with 70.7 V systems. The unit ships with a white powder‑coated CRS baffle featuring concealed mounting studs and includes screw‑mount hardware. Plus, its Hyfidrophobic™ coating provides moisture resistance—making it suitable for high‑humidity environments like bathrooms or outdoor entertainments spaces.
Key Features
- Full-size 8‑Inch woofer paired with 3‑Inch tweeter and built‑in crossover
- Wide 45 Hz – 19 kHz nominal frequency response
- 96 dB average sensitivity (1 W/1 m)
- 105‑Degree dispersion (2 kHz octave band)
- Premium 8‑watt, 70.7 V transformer (1, 2, 4, 8 W taps) with only 0.6 dB insertion loss
- White powder‑coated CRS baffle with concealed mounting studs
- Moisture-resistant Hyfidrophobic™ coating on baffle
Technical Specifications
- Speaker Type: Treated Paper
- Frequency Response: 50 Hz – 15 kHz
- Sensitivity: 96 dB (Average)
- Power Taps: 1, 2, 4 & 8 Watts
- Dispersion: 105 Degree (‑6 dB points at 2 kHz)
- Diameter: 8‑1/8‑Inch (20.6375 cm)
- Safety Listed: 1480, 2043
- Warranty Period: 60 months
