Audac APC100 MK2 Universal Configuration and Control Unit
Audac APC100 MK2 Universal Configuration and Control Unit
The Audac APC100 MK2 Universal Configuration and Control Unit is a powerful configuration and control unit designed to streamline installation, management, and control of your entire audio system. Effortlessly integrate a wide range of AUDAC smart devices, including matrix systems, mixers, paging consoles, and wall panels.
Save time and frustration with the APC100's versatile communication options. Utilize TCP/IP, RS-232, and RS-485 ports to seamlessly connect all your devices, establishing a central hub for effortless system control.
Simplified Configuration and Effortless Updates: Perform complex system configurations and updates with ease. The APC100 ensures system security with convenient backup and restore functionalities. Streamlined file management allows you to upload voice messages and screensavers directly using the unit and a computer.
Precision Timing and Advanced Software Integration: An internal real-time clock allows for synchronized time-controlled events across external devices. The AUDAC System Manager Software provides comprehensive control over the APC100 and all connected smart devices.
Gateway Functionality and Flexible Mounting Options: Integrate non-networked devices like audio sources and power amplifiers using the APC100's serial-to-TCP/IP conversion capabilities. Choose from a variety of mounting brackets (sold separately) for desk, closet, or 19-inch equipment rack installation.
Upgrade your audio system's efficiency and control with the AUDAC APC100. Buy today!
Key Features
- Compact design for easy installation and space-saving solutions
- Control options available through RS232 and TCP/IP ports
- Efficient digital communication via RS-485 bus
- S-box™ enclosure offers modular and multifunctional capabilities
Technical Specifications
Available models
APC100MK2
MK2 version
System Information
Control
RS-485
RS-232
TCP/IP
Connectors
RJ45 (Ethernet)
2 x RJ45 (RS-485 + Audio)
DB9 (RS-232)
Power Consumption
< 1 W
Supply
24V DC (PSD242 switching Power supply included 100 ~ 240V AC / 47 ~ 63 Hz)
Socket Connections (AUDAC Touch™)
4 sockets
