Audac PMQ240 WaveDynamics Quad-Channel 100V Power Amplifier, 240 Watts

Audac PMQ240 WaveDynamics Quad-Channel 100V Power Amplifier, 240 Watts

The PMQ series are professional 100V quad channel power amplifiers, providing a new standard for premium sound 100V amplification in public address applications. Their advanced features and availability in different output powers provide an enormous flexibility for numerous applications. The PMQ240 is a four channel Class-D 100V power amplifier with an output power of 240 Watt for each channel. The WaveDynamics DSP processor combination with the 2.5” LCD display gives an unmatched user experience with intuitive functions overview for easy configuration.

Key Features

• Scroll-Push control
• WaveDynamics DSP and loudspeaker management
• 2.5” LCD display
• Individual channel selectors & indicators (4x)
• USB connection for preset or settings loading / storage
• Terminal block output connections
• XLR & terminal block input & linkthrough connections
• Dante expansion port for optional ANI44XT
• Temperature controlled fan

Technical Specifications

RMS Power
4 x 240 W
Signal / Noise
> 95 dB
THD+N (@ 1 kHz)
< 0.05% (1/2 Rated Power)
Crosstalk (@ 1 kHz)
> 70 dB
Technology
Class-D
Common mode rejection ratio
70 dB
Damping factor
> 200
Operating temperature
0 ~ 40 @ 95% Humidity
Dimensions
18.98 x 3.46 x 16.54 “ (W x H x D)
Weight
17.75 lb
Unit height
2 HE
Construction
Steel
Colors
Black
