Audient iD14 2 Channel USB2 Interface Monitoring System
iD14 delivers the audio performance of a large format console in a compact and elegant desktop package. iD14 provides a pair of world-class Audient console mic pres, class-leading Burr Brown converter technology, console style monitor control, JFET D.I and the revolutionary ScrollControl. With its versatile feature set and intuitive layout, iD14 will become the hub of your studio in no time.
Key Features
- 10-in/4-out USB Audio Interface
- 2 x Class-A Audient Console Mic Preamplifiers
- High Performance Burr Brown AD/DA Converters
- iD ScrollControl Mode
- 1 x Discrete JFET Instrument Input
- Main Speaker Output
- Independent Class-AB Headphone Output
- Full Monitor Control Functionality (software controlled)
- ADAT Input for Expandability
- Low Latency DSP Mixer
- USB2.0 Bus Powered
- 24bit/96khz
- All-Metal Enclosure
Technical Specifications
MICROPHONE PREAMPLIFIER
MIC GAIN
0 to 66 dB (inc. +10 dB software boost)
LINE GAIN
-10 to 56 dB (-10dB hardwired line pad)
PHANTOM POWER
48V ±4V @ 10mA/Channel (12VDC only)*
MIC EIN
<-127.0 dBu
CMRR
>80 dB @ 1kHz
MAXIMUM INPUT LEVEL
+12 dBu (0 dBFS digital Maximum)
INPUT IMPEDANCE (Mic)
2.8 k Balanced
INPUT IMPEDANCE (Line)
>8k Balanced
FREQUENCY RESPONSE
±0.1 dB 20Hz to 22kHz @ min. gain
±1.0 dB 20Hz to 22kHz @ max. gain
CROSSTALK
<-90 dBu
THD+N @ 0dBu (1kHz)
0.0025% (-92 dBu)
SNR
96 dB un-weighted, 99 dB A-weighted
XLR Combi Female
Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4" TRS Jack
Tip (Hot), Ring (Cold) & Sleeve (Shield)
D.I (Channel 1)
D.I GAIN
0 to 66 dB (inc. +10 dB software boost)
MAXIMUM INPUT LEVEL
+9 dBu (0.6% THD typical)
INPUT IMPEDANCE
>500k Unbalanced
FREQUENCY RESPONSE
±0.1 dB 20Hz to 22kHz
THD+N @ 0dBu (1kHz)
<0.04% all musical 2nd and 3rd harmonics
SNR
95 dB un-weighted, 98 dB A-weighted
1/4” JACK
TIP (Hot) & SLEEVE (Shield)
USB 2.0 HIGH SPEED
BUS POWER
500mA @5V System Limit
425mA @5V Maximum (No 48V)
(Phantom power only available on 12VDC)*
No. of INPUT CHANNELS
10 (2 Analogue, 8 Digital)
No. of OUTPUT CHANNELS
4 (4 Analogue)
DSP MIXER LATENCY
ROUND TRIP (in-to-out)
44.1kHz 1.660ms
48.0kHz 1.531ms
88.2kHz 0.844ms
96.0kHz 0.771ms
Dimensions
Height
120mm
Width
173mm
Weight
1.25kg
