Audient iD4 1 Channel USB2 Interface Monitoring System
iD4 delivers the audio performance of a large format console in a portable desktop package enabling you to record your vocals and guitar simultaneously. Providing one renowned Audient console mic pre, class-leading converter technology, dual headphone outputs, console style monitor control, JFET D.I and our virtual scroll wheel technology 'ScrollControl', iD4 is a professional but affordable solution for your home studio or for when you’re on the road.
Key Features
- 2-in/2-out USB Audio Interface
- 1 x Class-A Audient Console Mic Preamplifier
- 1 x Discrete JFET Instrument Input
- High Performance Converters
- iD ScrollControl Mode
- Zero Latency Monitoring with Monitor Mix & Pan
- Main Speaker Output
- Class-AB Headphone Amplifier with Dual Outputs
- Monitor Control Functionality
- USB2.0 Bus Powered
- 24bit/96khz
- All-Metal Enclosure
- Windows, macOS and iOS compatible
Technical Specifications
MICROPHONE PREAMPLIFIER
MIC GAIN
0 to 58 dB
LINE GAIN
-10 to 48 dB (-10dB hardwired line pad)
PHANTOM POWER
48V ±4V @ 10mA/Channel
MIC EIN
<-126.0 dBu
CMRR
>75 dB @ 1kHz
MAXIMUM INPUT LEVEL
+12 dBu (0 dBFS digital Maximum)
INPUT IMPEDANCE (Mic)
2.8 k Balanced
INPUT IMPEDANCE (Line)
>8k Balanced
FREQUENCY RESPONSE
±0.1 dB 20Hz to 22kHz @ min. gain
±1.0 dB 20Hz to 22kHz @ max. gain
CROSSTALK
<-91 dBu
THD+N @ 0dBu (1kHz)
0.0015% (-96.5dBu)
SNR
96 dB un-weighted, 99 dB A-weighted
XLR Combi Female
Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4" TRS Jack
Tip (Hot), Ring (Cold) & Sleeve (Shield)
D.I (Channel 1)
D.I GAIN
-5 to 35 dB
MAXIMUM INPUT LEVEL
+8 dBu (0.6% THD typical)
INPUT IMPEDANCE
>500k Unbalanced
FREQUENCY RESPONSE
±0.1 dB 20Hz to 22kHz
THD+N @ 0dBu (1kHz)
<0.1% all musical 2nd and 3rd harmonics
Typically 0.05% at 0dBu
SNR
87 dB un-weighted, 90dB A-weighted
1/4” JACK
TIP (Hot) & SLEEVE (Shield)
ANALOGUE TO DIGITAL CONVERTER (ADC 1 & 2)
MAXIMUM INPUT LEVEL
+12 dBu (0 dBFS digital maximum)
DIGITAL REFERENCE LEVEL
+12 dBu = 0 dBFS
FREQUENCY RESPONSE
±0.1 dB 10Hz to Fs/2 (flat to nyquist)
CROSSTALK
-100 dBu @ 1kHz & 10kHz
THD+N @ -1dBFS (1kHz)
<0.001% (-100 dB)
THD+N @ -6dBFS (1kHz)
<0.0011% (-99.1 dB)
DYNAMIC RANGE
112 dB un-weighted
114 dB A-weighted
COMPATIBILITY
macOS 10.7.5 and later
Windows 7 and later
iOS 6 and later
Dimensions
Height
120mm
Width
133mm
Weight
1.0 kg
