SoundTube IPD‑HUB 2 2‑Channel Dante Network DSP Amplifier
The IPD‑HUB 2 is a two‑channel DSP amplifier powered via PoE/PoE+ or a 24 V DC power supply, designed for Dante/AES67 networked audio distribution. It is engineered for scalable commercial installations using passive loudspeakers and delivers up to 12 W per channel over 40 W PoE power.
Equipped with both Dante and local (Axiom) inputs, the unit supports local and network-based volume control and source selection. Integrated DSP offers mixing, equalization, and preset recall functionality. A compact rack or surface mount design with a standard 2‑inch form factor allows flexible deployment.
Includes AC‑HUB2‑CBL‑RDL adapter cable. Warranty coverage follows SoundTube standard: five years on speakers and three years on electronics.
Key Features
- Power Options: PoE, PoE+, 40 W PoE, or 24 V DC input
- Power Output: 12 W per channel (with 40 W PoE)
- Inputs: Dante™, Axiom local input, 2 RJ45 ports
- Outputs: Phoenix‑style terminals driving (2) 8 Ω or (4) × 16 Ω passive speakers
- Integrated DSP: Input mixing, EQ, preset recall, paging priority support
- Control options: Local via RVC‑1 or Axiom C1, or network via STNet/unIFY control center
- Certifications: CE, UL60065, UL2043, ETL‑C/US
- Compact Size: 1U‑height chassis (1.75″) with rack‑mount capability
- Included: AC‑HUB2‑CBL‑RDL adapter cable
Technical Specifications
- Height: 1.75″ (44.45 mm)
- Width: 8″ (203.2 mm)
- Depth: 6″ (152.4 mm)
- Weight: 7.71 lbs (3.50 kg)
- Power Output: 12 W per channel @ 40 W PoE
- Input Ports: 2 × RJ45, Dante, Axiom
- Power Inputs: PoE, PoE+, 24 V DC
- Speaker Compatibility: (2) × 8 Ω or (4) × 16 Ω passive speaker loads
- Control: STNet/unIFY, RVC‑1, Axiom C1
- Certifications: CE, UL60065, UL2043, ETL‑C/US
What’s Included
- IPD‑HUD 2 amplifier unit (black finish)
- AC‑HUB2‑CBL‑RDL RDL adapter cable
