Bestlink Netware 101015BK 1000ft Cat6 23AWG Shielded FTP CMR Bulk Cable, Black

Built for riser runs where foil shielding matters, Bestlink Netware's 101015BK puts 1,000 feet of Cat6 550 MHz shielded twisted-pair cable in a pull box. The four pairs are 23 AWG solid annealed bare copper under an overall aluminum foil shield, so installations near fluorescent ballasts, motors, lighting dimmers and other noise sources keep their headroom for Gigabit Ethernet and PoE devices.

The cable is ETL listed as CMR riser type FTP, c(ETL) listed FT4, and ETL verified to TIA-568-C.2 and ISO/IEC 11801 Category 6 performance. Polyethylene insulated conductors, a flame-retardant black PVC jacket and a 0.299 inch nominal outside diameter keep it compatible with standard Cat6 shielded keystones, patch panels and conduit fill calculations, and the built-in rip cord speeds up jacket stripping at every termination.

Rated for 10BASE-T through 1000BASE-T Gigabit Ethernet, ATM 155 Mbps and Token Ring, the 101015BK suits commercial AV, security camera backbones, access control and structured cabling projects. Installation temperature range is 0 to 60 C, operating range -20 to 75 C, and the cable is RoHS compliant.

Features

• 1,000 ft (305 m) of Cat6 550 MHz shielded (F/UTP) cable in a pull box, black jacket
• 23 AWG solid annealed bare copper conductors, 4 twisted pairs
• Overall aluminum foil shield with rip cord for fast jacket removal
• CMR riser rated: ETL listed CMR type FTP, c(ETL) listed FT4
• ETL verified to TIA-568-C.2 and ISO/IEC 11801 Category 6 performance
• Supports 10BASE-T, 100BASE-TX, 1000BASE-T Gigabit Ethernet, ATM 155 Mbps and 16 Mbps Token Ring
• Polyethylene insulation with a flame-retardant PVC jacket, 0.299 in nominal OD
• RoHS compliant

Technical Specifications

• Category: Cat6 Enhanced, 550 MHz, shielded (F/UTP)
• Length: 1,000 ft pull box
• Conductor: 23 AWG solid annealed bare copper, 4 pairs
• Shield: Overall aluminum foil, with rip cord
• Insulation: Polyethylene, 0.045 in OD; Jacket: Flame-retardant PVC, 0.0236 in wall
• Nominal Outside Diameter: 0.2992 in (+/- 0.008 in)
• Characteristic Impedance: 100 +/- 15 ohms (1-350 MHz)
• Max Conductor DC Resistance: 9.38 ohms / 100 m at 20 C; Mutual Capacitance: 5.6 nF / 100 m max
• Attenuation: 19.80 dB / 100 m at 100 MHz; 32.85 dB / 100 m at 250 MHz
• NEXT: 44.3 dB min at 100 MHz; Delay Skew: 45 ns / 100 m max
• Ratings: ETL listed CMR, c(ETL) FT4, ETL verified TIA-568-C.2 and ISO/IEC 11801, RoHS
• Installation Temperature: 0 to 60 C; Operating Temperature: -20 to 75 C
• Color Code: Pair 1 white/blue-blue, Pair 2 white/orange-orange, Pair 3 white/green-green, Pair 4 white/brown-brown
• Jacket Color: Black; Nominal Weight: 42 lb
• Manufacturer Part Number: 101015BK

What's Included

• One 1,000 ft pull box of Bestlink Netware 101015BK Cat6 shielded riser cable, black
