Blackmagic Design HyperDeck Extreme Control for Broadcast Deck

Blackmagic Design HyperDeck Extreme Control for Broadcast Deck

The Blackmagic Design HyperDeck Extreme Control for Broadcast Deck is the ultimate addition to any broadcast setup, enhancing your HyperDeck Extreme 8K with traditional broadcast deck controls. Its design mirrors that of classic broadcast decks, ensuring a familiar and intuitive layout for professionals in the broadcasting industry. Whether you are managing live events or in a studio setting, the HyperDeck Extreme Control offers unmatched reliability and precision. You can control up to 8 decks simultaneously via industry-standard RS-422 control, providing seamless integration with your existing equipment.

Designed with both modern and traditional broadcasting needs in mind, the HyperDeck Extreme Control's robust build and plethora of connectivity options make it an indispensable tool in any broadcasting environment. Its user-friendly interface and wide range of supported protocols ensure that it can easily adapt to various operating systems and configurations. The inclusion of an internal power supply as well as an external 12V DC input guarantees that the device remains operational under all conditions.

Key Features

• Traditional broadcast deck controls for HyperDeck Extreme 8K
• Familiar and intuitive layout
• Control up to 8 decks via RS-422
• Tri-Sync or Black Burst reference input
• 1Gb/s Ethernet port for seamless connectivity
• USB-C for software updates
• Supports Sony control protocols
• Internal software upgrades via system start or USB port
• Compatible with both Mac and Windows operating systems
• 8-digit, 7-segment LED timecode display
• Internal power supply and external 12V DC input
• 3 rack units height, half-rack width for easy installation

Specifications

• Deck Control Outputs: 8 x RS-422
• Reference Input: Tri-Sync or Black Burst
• Reference Output: Follows reference input
• Ethernet: 1Gb/s
• Computer Interface: 1 x USB-C for software updates
• Supported Protocols: Sony
• Operating Systems: Mac 10.13 High Sierra, Mac 10.14 Mojave or later; Windows 8.1 or Windows 10
• Displays: 8-digit, 7-segment LED timecode display
• Power Supply: 1 x Internal 100 - 240V AC; 1 x 4 pin XLR 12V DC IN
• Physical Installation: 3 rack units height, half rack width
• Operating Temperature: 0 to 40 deg C (32 to 104 deg F)
• Storage Temperature: -20 to 60 deg C (-4 to 113 deg F)
• Relative Humidity: 0% to 90% non-condensing

Package Contents

• HyperDeck Extreme Control
• SD card with user manual
• 12 Month Limited Manufacturer's Warranty
