Blizzard Lighting MystACL Z IP XL 20x 40W RGBW 4-In-1 Outdoor LED Batten Moving Head Fixture

MystACL Z IP XL: Dual Zoom Effects for Captivating Visual Displays
MystACL Z IP XL is an innovative and versatile moving head fixture that features 20x 40W RGBW LEDs. Designed with a focus on creating captivating visual displays in outdoor environments, the IP65-rated fixture boasts an innovative dual-zoom control system. The light source is split into two separate zones, each with 10 LEDs, and can operate either separately or together to produce full-length and split-row 3-60° beam/wash effects.

Loaded with Features for Unmatched Performance
This fixture comes equipped with a wide range of features, including dual-group pixel mapping and full pixel mapping capabilities. In addition, it features a unique three-layer set in 35-channel DMX mode, which allows adjustable pixel layer lengths of two overlapping groups of user-selectable background colors or patterns.

The sleek and weatherproof design of the MystACL Z IP XL supports 3/5-pin DMX and ArtNet. It also features an LCD control menu with touch-sensitive buttons, making it easy to navigate. Other notable features include built-in macros with patterns and multiple color presets, smooth electronic dimming, 1-20Hz strobe effects, and an efficient low noise fan cooling system.

Certified Quality and Reliability
MystACL Z IP XL fixtures are ETL listed and backed by Blizzard’s 2-year limited warranty, ensuring maximum quality and reliability. The fixture also features a retractable end-to-end fixture alignment system, 5-pin DMX + RJ45 input/output connections, PowerCON TRUE1-compatible power input/output, and dual omega brackets with 1/4-turn fasteners.

Key Features

• MystACL Z IP XL - an advanced LED Light.
• Equipped with 20x 40W RGBW flicker-free 4-in-1 LEDs.
• Endurance of long-lasting 50,000 hours.
• Features dual zone 3-60° motorized beam/wash effects.
• 8-16 bit motorized 205-degree tilt capability.
• Supports single or dual pixel mapping via DMX.
• Three-layer effects facilitated by DMX, inclusive of pixel sets and macros.
• Consists built-in macros, multiple color presets, plus patterns.
• Smooth electronic dimming & 1-20Hz strobe effects incorporated.
• Installed with an efficient, low noise fan cooling system.
• Contains retractable system for end-to-end fixture alignment.
• 5-pin DMX + RJ45 input/output connections for connectivity.
• PowerCON TRUE1-compatible power input/output included.
• Comes with dual omega brackets with 1/4-turn fasteners.

Technical Specifications

Optical
20x 40W RGBW 4-in-1 LEDs (50,000 hrs.)
3-60° zoom (dual zone)
Luminous Intensity
14,211 Lux @ 2.5M (3°)
3,389 Lux @ 2.5M (60°)
8,057 Lux @ 5M (3°)
965 Lux @ 5M (60°)
Control
Protocol
USITT DMX-512, Art-Net
3/5-pin DMX in/out
16/35/47/50/87/89 DMX channel modes
LCD control menu
DMX512, M/S, auto mode
Power & Current
100-240VAC, 50-60 Hz
Consumption
641W, 5.54A, PF .99
PowerCON TRUE1-compatible in/out
Dimensions
15” x 40.7” x 7.5”
56.3lbs
