Blustream PRO-OUT4TLS-V2 Pro Matrix 2X HDBaseT 2x HDMI 18G Output Board
Blustream PRO-OUT4TLS-V2 Pro Matrix 2X HDBaseT 2x HDMI 18G Output Board
The Blustream PRO-OUT4TLS-V2 output board offers 4x dual HDBaseT outputs for connection to a HDBaseT receiver and HDMI display per zone. The PRO-OUT4TLS-V2 utilizes CSC technology allowing support of HDMI 2.0 4K @ 60Hz 4:4:4 (18Gbps) HDCP 2.2 signal distribution up to lengths of 70m (4K to 40m). The PRO-OUT4TLS-V2 features independent downscaling of 4K video inputs on the CSC HDBaseT outputs to allow displays only capable of supporting lower video resolutions to receive 4K video while still showing maximum original 4K UHD resolution on the higher-definition displays. The PRO-OUT4TLS-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.
Key Features
- Advanced HDBaseT technology offering distribution of video and audio over a single CAT cable
- Features 4x simultaneous HDMI/HDBaseT outputs for connection to HDMI displays and HDBaseT receivers
- Advanced Color Space Conversion (CSC) supports HDMI 2.0 18Gbps specification including HDR support
- Supports 4K @ 60Hz 4:4:4 UHD video up to 40m*
- Independent downscaling of video input resolutions up to 4K @ 60Hz 4:4:4 to the following formats:
- 1080p @ 60Hz (for screens that do not support 4K)
- 4K @ 60Hz 4:2:0 (for screens that do not support full 4K @ 60Hz 4:4:4)
- Extends HDMI 1080p video up to 70m
- Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
- Supports PoH (PoE) to power Blustream HDBaseT Receivers
- Quick release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
- HDCP2.2 Support
- To be used with the HEX70CS-RX receivers
- *For HDMI 2.0 18Gbps video distribution the PRO-OUT4TLS-V2 must be used with a HDMI 2.0 18Gbps Custom Pro input board
Technical Specifications
Video Output Connectors
4x HDMI Type A, 19-pin, female, 4x HDBaseT RJ45 connector
Card Dimensions (W x H x D)
182mm x 22mm x 177mm
Dimensions Including Connections (W x H x D)
202mm x 22mm x 188mm
Shipping Weight
0.5kg
Operating Temperature
32°F to 104°F (0°C to 40°C)
Storage Temperature
-4°F to 140°F (-20°C to 60°C)
Item Includes
1x PRO-OUT4TLS-V2
Warranty
3 Year Warranty
