Bolin Technology EXU420F 4K60 Live Production Outdoor PTZ Camera

The Bolin EXU420F is a professional-grade outdoor PTZ camera engineered specifically for demanding live production environments. Featuring true 4K60 video capture with a high-performance Sony image sensor and 20X optical zoom (plus 16X digital), this rugged camera delivers stunningly smooth, detailed footage with exceptional color accuracy and clarity, even in challenging lighting conditions. The camera's advanced image processing engine utilizes AI-based algorithms to provide remarkable low-noise performance, enhanced dynamic range, and precise auto-focus capabilities, making it ideal for capturing everything from wide venue shots to detailed close-ups in outdoor broadcasts, sports coverage, live events, and remote productions.

Built to withstand harsh environmental conditions, the EXU420F features an IP67-rated weatherproof housing that ensures reliable operation in rain, dust, snow, and extreme temperatures. Its comprehensive connectivity options include dual 12G-SDI outputs, HDMI 2.0, SFP optical expansion, and FPGA-powered FAST HEVC IP streaming that delivers high-quality video at remarkably low bandwidth (as low as 50Mbps for 4K60). Advanced production features include FreeD protocol support for virtual/augmented reality integration, precise PTZ movement with 255 preset positions, and True Dual-Output technology allowing independent resolution settings for baseband and IP outputs. Whether deployed for live sports, outdoor concerts, traffic monitoring, or situational awareness, the EXU420F combines exceptional image quality, rugged reliability, and broadcast-grade features in a versatile package that meets the demanding requirements of professional outdoor productions.

Key Features

• True 4K60 Video Capture: Delivers fluid, ultra-high-definition footage at 60fps with exceptional detail and smooth motion, perfect for fast-action live events and sports
• Professional 20X Optical Zoom: High-quality lens with precision 20X optical zoom and additional 16X digital zoom provides remarkable flexibility for wide shots and detailed close-ups
• Sony Image Sensor with AI Processing: 1/2.5" Sony IMX715 sensor paired with advanced AI-based image processing delivers superior color accuracy, detail, and low-light performance
• IP67 Weatherproof Design: Rugged construction withstands harsh outdoor conditions including rain, dust, snow, and temperature extremes for reliable 24/7 operation
• FPGA-Powered FAST HEVC Encoding: Hardware-accelerated video processing delivers high-quality, ultra-low latency, low-bandwidth IP streaming (as low as 50Mbps for 4K60)
• Comprehensive Connectivity: Multiple simultaneous outputs including dual 12G-SDI, HDMI 2.0, SFP optical expansion, and IP streaming support (RTSP, RTMP, RTMPS, SRT)
• FreeD Protocol Support: Enables seamless integration with virtual production systems for immersive AR/VR applications and automated tracking
• Precise PTZ Control: Smooth, accurate movement with 340° pan range, 210° tilt range, and 255 preset positions with 0.03° accuracy

Technical Specifications

• Image Sensor: 1/2.5" Sony IMX715 CMOS
• Video Resolution: Up to 4K60 (3840×2160 at 60fps)
• Optical Zoom: 20X with 16X additional digital zoom
• Viewing Angle: 79° horizontal (wide end)
• Pan/Tilt Range: Pan 340° (-170° to +170°), Tilt 210° (-90° to +120°)
• Pan/Tilt Speed: 0.01° to 60°/s (fully proportional)
• Weatherproofing: IP67-rated housing
• Control Protocols: VISCA, VISCA-over-IP, Pelco P/D, ONVIF

Package Contents

• Bolin EXU420F 4K60 Outdoor PTZ Camera
• IR Remote Controller
• Drop-prevention Wire
• Drop-prevention Wire Mounting Screw
• Cable Cover
• Seal Rings
• Quick Install Panel Bolts
