Camplex CMX-3G-4SDI 4 Channel 3G SDI Multiplexer Over Singlemode Fiber Extender

The Camplex CMX-3G-4SDI multiplexer simplifies 3G-SDI broadcast quality distribution by combining up to 4 cameras or 3G-SDI sources and converting them to a one singlemode fiber run. Not only will the CMX-3G-4SDI overcome the longest of traditional coaxial distance limitations, but will also overcome signal loss and interference issues inherent in a long length copper cable. The conversion to a single fiber run saves install time making shoots quicker to set up and more cost effective versus running 4 separate camera feeds.

The CMX-3G-4SDI is a complete transmitter and receiver kit delivering plug-and-go operation right out of the box. Each unit houses industry standard ST locking fiber connectors as well as 3G-SDI BNC connections. The transmitter and receiver support SMPTE-424M 3Gbps HD-SDI for transmission up to 6 miles. Add in a Camplex tac reel and you're ready for any 4 camera shoot at sports venues, live productions or public access events.

Key Features

• Converts 4 - 3G SDI camera inputs to one singlemode fiber
• Saves space and set up time
• Extends transmission distance
• Immune to EMI
• Supports SMPTE-424M 3Gbps HD-SDI transmission up to 6 miles
• Industry Standard ST Fiber Connectors
• Auality 3G-SDI BNC Connectors
• DC Power Jack

Technical Specifications

Input Power
12VDC
Power Consumption
8W
Dimensions
6.6 x 6.06 x 1.77 in/168 x 154 x 45mm (each unit)
Weight
2.75 lb/1.25kg (each unit)
