Camplex CMX-HDMI-SFP Single Fiber SFP 4K HDMI 2.0 Extender with Bidirectional IR RS-232
Extend 4K HDMI beyond distances you ever imagined possible with the Camplex HDMI-SFP fiber optic HDMI 2.0 extender. It is the perfect match for eSports arenas, concert venues, stadium digital signage applications and wherever distributing a crystal clear 4K HDMI 2.0 18G signal over long distances is required. The Camplex HDMI-SFP fiber extender supports video resolutions up to 4K2K@50/60Hz and takes full advantage of single mode cables to drive signals over 3300 feet (1000 meters). It is also compatible with multimode fiber for driving 4K HDMI over fiber up to 1000 feet (300 meters 50/125m/OM3). It features bi-directional infrared control and RS-232 signals transmission to allow source distance operation of additional sources, commercial insertion sources and more.
Key Features
- Transmission Up to 3300 Feet over Single Mode Fiber
- Single Fiber Simplex Operation
- Video Resolutions up to 4K2K@50/60Hz (YUV 4:4:4)
- Bi-directional Infrared Control
- Bi-Directional RS-232 Transmission
- LED Indicators for Power, Optical, & HDMI
- Rugged, Black Powder-Coated Metal Housing
- Locking Power Adapters
- CE, RoHS Certified
Technical Specifications
Compliance
HDMI 2.0b (18Gbps), HDCP 2.2, DVI
Video Bandwidth
18Gbps
Video Resolutions
up to 4K2K@50/60Hz(YUV4:4:4),4K2K@30Hz,1080P@120Hz, and 1080P 3D@60Hz
Color Space
RGB, YCbCr 4:4:4, YCbCr 4:2:2 / Color Depth: 8-bit, 10-bit, 12-bit
HDMI Audio Formats
LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
Transmission Distance
up to 3300 feet/1000 meters over single-mode and up to 1000 feet/300 meters over multi-mode (50/125m/OM3)
IR Frequency
20KHz-60KHz
RS-232 Baud Rate
4800-115200bps
TX Input
1-HDMI Type A, 1-IR In (3.5mm Stereo Mini-Jack), 1-RS-232 (3.81mm Phoenix Connector)
TX Output
1-Optical Fiber Out (LC Female), 1-IR Out (3.4mm Stereo Mini-Jack)
RX Input
1-Optical Fiber In (LC Female), 1-IR In (3.5mm Stereo Mini-Jack)
RX Output
1-HDMI Type A, 1-IR Out (3.5mm Stereo Mini-Jack, 1-RS-232 (3.81mm Phoenix Connector)
Power Consumption
3W
Power Input
AC100 - 240V 50/60Hz
Dimensions (each unit)
6.375 (w/mounting ears) x 2.7 x 0.75in / 162 x 68.58 x 19.05mm
Weight
TX: 9.03 oz/256g, RX: 9.17 oz/260g
