Camplex CMX-TACNGO-C3G 1000 Foot Fiber Optic Converter Extender Cable Reel System
The Camplex CMX-TACNGO-C3G is a complete cost-effective 3G-SDI to singlemode fiber optic converter and field deployable cable reel system that converts and extends your 3G-SDI signals over 1000 feet of tactical fiber optical cable. Utilizing the Camplex CMX-3GSDI-LCF SDI to fiber converter system, the transmitter is built into a super rugged cable reel and connected to 1,000 feet of tactical grade fiber optic cable delivering the handy convenience of rapid field deployment.
Key Features
- Convert 3G-SDI SMPTE 424M to fiber signals for long haul fiber cable reel deployments
- Super rugged cable reel for fast and easy field deployment
- Reel: ST feed through barrels with metal dust covers on chains
- Supports SDTV (143-540Mbps)/HDTV (1.485Gbps, and 3Gbps, 1080p60) image transmissions
- Simplex LC singlemode fiber connection
- Automatic cable equalization and re-clocking
- 1 channel video and audio transmission of digital video signal over fiber
- Extends transmission capability up to 49.7 miles (80 km)
Technical Specifications
SMPTE 292M and SMPTE 259M standards
Transmitter
1 channel SDI with looping output
Receiver
2 channel SDI output
Wavelength
1310nm
Optic fiber
9/125u singlemode
Optical connector
Simplex LC/PC
Input power
5 VDC/12 VDC
Power consumption (max)
Transmitter: 1.8W, Receiver: 1.5W
