Chauvet Professional COLORado Solo Edge 3 LED Footlight

Chauvet Professional COLORado Solo Edge 3 LED Footlight

Chauvet Professional COLORado Solo Edge 3 is an LED footlight designed for stage edge and performance lighting environments. It enables smooth color and white light output for lighting designers and production teams, supporting stage illumination and edge definition workflows. This makes it ideal for stage and event applications where even output and clear boundary marking are critical.

The fixture uses a single-source lens to produce smooth, even output and includes controllable RGB marker lights for cueing talent or marking the edge of a stage. It supports end-to-end alignment for continuous runs and includes a covered display to keep controls discreet. Control integration is supported through Art-Net, DMX, and sACN protocols.

This footlight is built for use in touring, rental, and installed environments where durability and consistent operation are important. Its IP65 rating supports outdoor and wet-use scenarios. The stealth filter and low-profile design help reduce visual presence when the fixture is not in use.

Key Features

• Low-Profile Footlight Design: Supports discreet placement for stage edge and performance lighting applications.
• Single-Source Lens Output: Produces smooth, even output with no distracting points of light.
• RGB Marker Lights: Fully controllable marker lights can cue talent or mark the edge of a stage.
• End-to-End Alignment: Designed for continuous runs with minimal gaps and reduced cable clutter.
• Stealth Filter Support: Includes a stealth filter to help the fixture disappear when off.
• IP65 Outdoor Rating: Rated for outdoor and wet-use applications with IP65 protection.

Technical Specifications

Optical
Light Source: 112 LEDs (Quintuple-color-RGBwWL), K 20,000 hours life expectancy
Color Temperature (range): 2800 to 8000 K
Color Temperature (at full): 6600 K
CRI (2800): 93
Beam Angle: 111° (Horizontal)
Beam Angle: 120° (Vertical)
Field Angle: 134° (Horizontal)
Field Angle: 161° (Vertical)
Lumens: 17,698
Illuminance (total): 221 lux @ 5 m
PWM Frequency: 1000Hz, 2000Hz, 4000Hz, 6000Hz, 25KHz or 64KHz
Selectable PWM: 1000Hz, 2000Hz, 4000Hz, 6000Hz, 25KHz or 64KHz

Dynamic Effects
Dimmer: Electronic
Shutter/Strobe: Electronic
Framing Shutters: No
Strobe Rate: 0 to 30Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Dim Curves: 4
Built-in Automated Programs: Yes
Customizable Programs: Yes
Recall Custom Programs: Yes/No

Construction / Physical
Dimensions: 39.37 x 8.85 x 2.51 in (1000 x 225 x 64mm)
Weight: 22.0 lb (10 kg)
Exterior Color: Black
Housing Material: Aluminum alloy and Aluminum diecast

Connections
Power Connection: Edison (Local) plug to Seetronic Powerkon IP65
Power Input: Seetronic Powerkon IP65
Power Output: Seetronic Powerkon IP65
Data Connectors: 5-pin XLR
Cable Length (power): 5 ft (1.5 m)

Control
Control Protocol: Art-Net, DMX, sACN
DMX Channels:
1 Cell: 5, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
4 Cell: 14, 15, 15, 18, 22, 33, 37, 41, 42 or 69
Art-Net Channels:
1 Cell: 5, 6, 6, 6, 7, 11, 12, 12, 13, 14 or 21
2 Cell: 8, 9, 9, 10, 12, 19, 21, 22, 23 or 37
4 Cell: 14, 15, 15, 18, 22, 33, 37, 41, 42 or 69
Modes/Personalities: 2 personalities (32)
Frequency (operating): 600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz or 25KHz

Electrical
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 5; 6 units @ 120 V; 10 units @ 208 V; 11 units @ 230 V
Power and Current: 242 W, 2.03 A @ 120 V, 60 Hz
Power and Current: 237 W, 1.18 A @ 208 V, 60 Hz
Power and Current: 236 W, 1.06 A @ 230 V, 50 Hz

Certifications / Qualifications
CE, MET, ROHS
IP Rating: IP65, outdoor/wet, with pressure equalizing M12 GORE valve
Temperature (Ambient): -4 °F to 113 °F (-15 °C to 45 °C)

What's in the Box
(1) COLORado Solo Edge 3
(1) Seetronic Powerkon IP65 power cord
Power and Data linking cables
Stealth Filter
Omega bracket with mounting hardware
