Christie D13WU2-HS 13500 Lumen WUXGA 1DLP Laser Projector

Enjoy the performance of advanced electronics. With 13,500 lumens, the Christie D13WU2-HS is equipped with advanced 1DLP laser projection technology to operate at full-brightness on a single 15A, 110V circuit. There’s no need for high-power runs. Simply plug into a standard outlet and start the show!

Visuals are stunning thanks to the enhanced color accuracy of Christie’s BoldColor Technology and WUXGA resolution. The long-lasting and reliable laser light source and affordability of 1DLP technology means the D13WU2-HS is a cost-effective option for high-use applications. Featuring the built-in Christie Twist warping and blending engine, and compatible with Christie Mystique automated camera-based alignment solutions, the D13WU2-HS gives you the tools you need to quickly and easily set up, align, and maintain irregular screens and multi-projector displays.

Key Features

• BoldColor Technology - Enhanced color performance and saturation over standard laser projection
• Long-life laser light source - Up to 20,000 hours to 50% brightness of virtually maintenance-free operation
• Warp and blend - Built-in Christie Twist for quick and easy setup of multi-projector displays
• Compatible with Christie Mystique - Automated camera-based alignment solutions that eliminate the challenges, time and expertise required to align, stack, warp and blend complex multi-projector arrays and projection mapping experiences
• Fully omnidirectional - Unrestricted design and installation flexibility
• Lens compatibility - Designed to work with all Christie HS Series lenses for added cost-savings and versatility
• Comprehensive connectivity - Full connectivity for popular formats including 3GSDI for added redundancies
• Advanced electronics - Firmware updates take only minutes
• Medical Training Capable DICOM simulation mode for advanced grayscale image reproduction, perfect for analyzing x-rays and medical scans for training purposes
• TAA Compliant

Technical Specifications

ISO lumens
13,500
ANSI lumens
12,500
Color wheel
4 Segment (RGBY) 2X or 3X speed
Contrast ratio
Full On/Off (Christie Real Black enabled): 2,000,000:1, Full On/Off (Christie Real Black disabled): 1,200:1
Dynamic contrast
6000:1
Display type
1 x 0.96” DMD
Resolution
WUXGA (1920 x 1200)
Illumination type
Laser phosphor with Christie BoldColor Technology
Illumination performance (hrs)
20,000 hours to 50%
Scan rates
Horizontal: 15-91kHz Vertical: 24-85Hz
Pixel clock rate
162MHz
Signal inputs
Standard
HDMI x 2 (one on rear panel, one on bottom of projector, independently selectable)
3GSDI (BNC)
DVI-D (digital only)
USB (type A) image viewer or WiFi dongle (optional)
HDBaseT (RJ45)
Signals
HDTV formats VGA through to WUXGA (1920 x 1200)
3D inputs
HDMI 1.4, HDBaseT frame packed, top/bottom, side-byside (up to 120Hz output)
3D Sync In (BNC) for genlocking projectors
3D Sync Out (BNC) for genlocking projectors or controlling emitters
Signal outputs
3GSDI (BNC)
HDMI x1 (HDMI out)
Control and networking
RS232 In
Control via HDBaseT
Ethernet (10/100) RJ45
Built-in backlit keypad
Wired remote control (3.5mm stereo) loop out available for daisy chaining
12VDC trigger at 200mA (ID:2.5mm)
Warping and blending
Standard
Christie Twist
Optional
Christie Twist Premium and Twist Pro
Christie Mystique automated camera-based alignment
Lens mount
Boresight adjustable
Motorized horizontal and vertical lens offset (memory available)
Motorized zoom and focus adjustment (memory available for full ILS lenses)
Lens options
Lenses
0.38:1 UST lens
0.84-1.02:1
1.02-1.36:1
1.2-1.5:1
1.5-2.0:1
2.0-4.0:1
4.0-7.0:1
Power requirements
Operating voltage
Normal: 120-240VAC @ 60/50 Hz with 15A fuse
Power consumption
Normal mode: 1050W
Eco1 mode: 900W
Eco2 mode: 600W
Operating current
Normal mode: 12A (100-240V)/ 7A(200-240V)
Dissipation
Normal mode: 5835 BTU/hr
Eco1 mode: 4709 BTU/hr
Eco2 mode: 2832 BTU/hr
Audible noise
Standard mode: 38dB(A), Eco2 mode: 35dB(A) (2x wheel speed)
Standard mode: 39dB(A), Eco2 mode: 37dB(A) (3x wheel speed)
Dimensions (L x W x H)
26.65 x 23.46 x 7.99” without feet
677 x 596 x 203mm without feet
Shipping dimensions
36.34 x 33.19 x 20.20”
923 x 843 x 513mm
Weight
91.52lbs (41.6kg)
Shipping dimensions (L x W x H)
37.99 x 31.30 x 14.37” (965 x 795 x 365mm)
Shipping Weight
117.7lbs (53.3kg)
Operating environment
Temp: 0 to 40° C (32 to 104° F)
Humidity: 10 85% non-condensing
Regulatory
Contact Christie for the timing of certifications
UL/CSA/IEC 60950-1 FCC Class A CE FDA CCC KC PSE CU BIS VCCI RCM TER
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS REACH WEEE
Limited warranty
Three years parts and labor on the projector
Three years or 20,000 hours parts and labor on the illumination system*
Contact an authorized Christie representative for full details of our limited warranty
*Please reference the Christie Standard Limited Warranty document for details.
Accessories
Standard
IR remote w/ wired remote jack (wire not included)
AC line cords for projector head
User manual
Optional
1DWUSB-BGN (wireless dongle for video and control)
HS fog filter covers + filters (order once per projector then only filters refills)
HS fog filter refills (1 set)
Replacement remote control
