Christie LWU650-APS 6500 Lumens 3LCD Laser Projector

The Christie LWU650-APS is a 6,500 lumen projector that combines the affordability of 3LCD technology with the reliability, performance and operational life of laser illumination. Perfect for environments like classrooms, boardrooms and conference rooms, the LWU650-APS is a professional-grade projector with a focus on value and quality.

Featuring an efficient laser illumination system and patented optical light path, the LWU650-APS provides up to 20,000 hours of reliable, maintenance-free operation for an extremely low cost of ownership. Backed by an unmatched five-year or 10,000-hour warranty (whichever occurs first) and a price-point that beats the competition, the LWU650-APS is the class-leader for 6,000-lumen-class projectors.

Key Features

• High-quality image performance - 6,500 ISO lumens, WUXGA resolution and at least 3,000,000:1 on/off contrast ratio produce amazing visuals
• Low-profile, lightweight and quiet design - Can be discretely installed in any setting
• On-board speaker - 16W built-in speaker for added functionality
• Omnidirectional - Increased installation flexibility
• Flexible connectivity - Comprehensive I/O options including HDBaseT
• Unbeatable warranty - Five-year or 10,000-hour warranty (whichever occurs first)
• Christie ScholarTech applicable - Enjoy even more price savings when you purchase through the Christie ScholarTech program

Technical Specifications

Brightness (lumens)
ANSI - 6000
ISO - 6500
Contrast
3,000,000:1
Display technology
0.64" 3LCD
Native Resolution
1920 x 1200 WUXGA
Illumination
Solid state laser
Typical lifetime
20,000 hrs
Signal Inputs
Computer Input: Mini-D-sub 15 -pin connector x 2
Digital Input: HDMI x 2, HDBaseT x1
Video Input: RCA connector x 1
Audio Input: 3.5mm stereo mini connector x 2, RCA connector (L/R x1)
USB Type A x 1(for wireless network)
Signal Outputs
Monitor out: Mini-D-sub 15-pin connector x 1
Audio output 3.5mm stereo mini connector x 1
Control and networking
D-sub 9-pin connector x 1 (RS-232C)
RJ45 port x 1
SNMP Management (SNMP)
Projector monitoring (wired LAN)
Control from a remote location (wired LAN)
E-mail Alerts (wired LAN)
Mirroring of PC Screen (using LiveViewer software)
Infrastructure Mode (Wireless LAN)
Simple Access Point (SoftAP)
Speaker
16W (Mono)
Zoom
Manual (x.17)
Focus
Manual
Lens shift
Manual (Vertical : 0-56.5%, Horizontal: +/-4.6%)
Keystone correction
Vertical/horizontal and 3D Keystone (PerfectFit)
Fits screen sizes
30-300"
Throw ratio
1.4-2.4
Throw distance @ 100"
3.0-5.2m
Scan rates
Horizontal: 31.5-106kHz/li>
Vertical: 56-120Hz
Max pixel clock rates
162MHz (1600x1200)
154MHz (1920x1200)
Operating voltage
100-120VAC @ 50/60Hz
220-240VAC @ 50/60Hz
Power consumption
420W +/- 10% @ 100-120 VAC
400W +/- 10% @ 220-240 VAC
Standby mode: 0.5W
Operating current
4.3A +/-10% @ 100-120 VAC
2.1A +/-10% @ 220-240 VAC
Dissipation
1502 BTU/hr @ 100-120V
1433 BTU/hr @ 220-240V
Audible noise
Standard mode: 37dB(A)
Eco mode: 28dB(A)
Size
(LxWxH) 19.92 x 5.43 x 16.7" (506 x 138 x 424mm)
Shipping size
(LxWxH) 21.7 x 26.9 x 9.0" (552 x 683 x 229mm)
Weight
18.7lbs (8.5kg)
Shipping weight
26.5lbs (12.0kg)
Temperature
0-2,625ft: 0-40C (Dimming at 35-40C )
2625 -10,000ft: 0-35C (Dimming at 30-35C)
Humidity
Humidity: 10-85% non-condensing
Key features
HDBaseT
AMX and Crestron connectivity
Extron XTP certified
DICOM simulation mode
HDCR
eClarity advanced image processing
Picture-in-Picture/Picture-by-Picture
3D Keystone
Portrait and 360 projection
Wireless capable
Accessories
Standard
Power Cable 1.8m (L type)
Computer cable (1.8m)
Lens cover and cap
IR remote controller without 2 AA batteries
Hook metal for drop-prevention chain
Adapter cover for USB wireless adapter
Optional
USB wireless adapter
Remote control
Wired remote controller
Filter set
Regulatory
Contact Christie for the timing of certifications: UL/CSA/IEC 60950-1, FCC Class A, CE, FDA, CCC, KC, PSE, CU, SABS, BIS, VCCI, RCM, Ukr, TER, SASO
This product conforms to all relevant European directives, standards, safety, health and environmental concerns
RoHS, REACH, WEEE
Warranty
Five years or 10,000 hours on the projector (whichever occurs first)
