Description
AuviTran AV-WALL-DT4i-B Dante Wall Plate Mic/Line Interface with Bluetooth
The AuviTran AV-WALL-DT4i-B is a professional Dante-enabled wall plate interface designed to connect microphones, line sources, and Bluetooth audio directly to a Dante audio network. Its ultra-compact design allows installation in a standard single-gang wall box while delivering professional-grade audio performance.
This interface includes two XLR microphone/line inputs with phantom power and a stereo mini-jack input for additional audio sources. Integrated mixing allows up to four input signals to be routed to Dante network channels, making the DT4i-B ideal for conference rooms, lecture halls, and AV installations.
Key Features
- Dante network microphone/line input interface
- 2 XLR microphone/line inputs with +48V phantom power
- Stereo 3.5 mm mini-jack input
- Optional Bluetooth audio integration
- Internal mixing of up to four audio inputs
- Rotary push button for local control
- PoE powered via RJ45
- Fits standard single-gang wall box
Technical Specifications
- Inputs: 2 XLR mic/line + stereo 3.5 mm mini-jack
- Sampling Rates: 44.1 / 48 / 88.2 / 96 kHz
- Bit Depth: 24 or 32 bit
- Input Sensitivity (XLR): +24 dBu to -40 dBu
- Dynamic Range: >101 dB
- Frequency Response: 20 Hz – 20 kHz
- Phantom Power: +48 V per channel
- Power: PoE (IEEE 802.3af)
- Maximum Consumption: 5.5 W
