SoundTube IPD-CI Series Addressable Dante/AES67 In-Ceiling Speaker
The SoundTube IPD-CI series delivers networked audio via PoE (40 W max) in a sleek, plenum-rated in-ceiling enclosure. Available in two driver sizes 5.25″ and 6.5″ each model features a coaxial polypropylene woofer with butyl-rubber surround and a 1″ silk-dome tweeter with BroadBeam Ring™ technology for uniform high-frequency dispersion. All audio, power, and control run over a single CAT5/CAT6 cable, with remote configuration and status monitoring through SoundTube’s STNet software.
Engineered for both commercial and residential Dante™/AES67 installations, the IPD-CI speakers are housed in a sealed drawn-steel backcan with a tuned port for enhanced bass response. UL2043 and plenum-rated, they’re ideal for retail, hospitality, corporate, and high-end residential applications.
Key Features
- Networked Audio: Dante™/AES67 with PoE (IEEE 802.3af, PoE+ compatible)
- Power Handling: 40 W PoE (max with STNet Switch II)
- Frequency Response (± 10 dB): 56 Hz – 22 kHz
- Frequency Response (± 3 dB): 67 Hz – 20 kHz
- Inputs: RJ45 Ethernet (data, power, control)
- Enclosure: Drawn steel backcan with tuned port, ABS/steel grill (paintable)
- Certifications: CE, RoHS, UL2043, UL60065, ETL-C/US, BAA/TAA
- Included Accessories: Conduit clamp, cover plate, magnetic grille, paint mask
Technical Specifications
- Shipping Weight: 9.05 lbs (4.11 kg)
- Max Ceiling Thickness: 1.6″ (40.6 mm)
- Min Ceiling Thickness: 0.04″ (0.9 mm)
- Tweeter: 0.75″ silk dome w/ BroadBeam Ring®
- Network Type High-Pass: 12 dB/octave, 2nd order
- Directivity Factor (Q): 4.3–4.2 (100 Hz–10 kHz avg @ 2 kHz)
- Directivity Index (DI): 5.7–6.2 dB (100 Hz–10 kHz avg @ 2 kHz)
- Visible Diameter: 11.8″ (298.5 mm)
- Visible Height (Grille): 0.34″ (8.6 mm)
What's Included
- Magnetic steel grille (paintable)
- Conduit clamp & cover plate
- Paint mask
Available Variations
-
IPD-CI52 (5.25″):
- Woofer: 5.25″ polypropylene cone w/ butyl rubber surround
- Crossover: 5.0 kHz
- Cutout Diameter: 10.5″ (266.7 mm)
- Backcan Diameter × Height: 9.67″ × 5.75″ (245.6 × 146.1 mm)
- Coverage Angle: 180° (±6 dB @ 2 kHz)
-
IPD-CI62 (6.5″):
- Woofer: 6.5″ polypropylene cone w/ butyl rubber surround
- Crossover: 5.0 kHz
- Cutout Diameter: 10.5″ (266.7 mm)
- Backcan Diameter × Height: 9.67″ × 5.75″ (245.6 × 146.1 mm)
- Coverage Angle: 180° (±6 dB @ 2 kHz)
