Williams AV SP-628L Lay-In Ceiling Speaker, Single Unit
The Williams AV SP-628L Lay-In Ceiling Speaker is designed for quick installation into standard 2' × 2' ceiling grids, providing full-range audio reproduction for classrooms, conference rooms, and other commercial environments. It integrates a 6.5″ woofer and 1″ tweeter in a sealed back can, ensuring high-quality sound while meeting plenum space requirements.
Constructed for durability and ease of installation, the SP-628L features a lightweight design, secure mounting via T-bar supports, and a white finish to blend seamlessly with ceiling tiles. This single speaker unit offers clear speech intelligibility and wide audio coverage, making it ideal for voice reinforcement systems.
Key Features
- Speaker Type: Full-range, lay-in ceiling speaker
- Driver Configuration: 6.5″ woofer + 1″ tweeter
- Coverage Pattern: Wide dispersion for even room coverage
- Installation: Fits standard 2' × 2' ceiling grids
- Back Can: Sealed metal enclosure for plenum-rated applications
- Color: White finish to match ceiling tiles
Technical Specifications
- Weight: 8 lb (3.62 kg)
- Dimensions (W × L × D): 12.25″ × 23.75″ × 6.25″ (31.11 × 60.32 × 15.87 cm)
- Dimensions with T-bar: 13″ × 23.75″ × 6.25″ (33.02 × 60.32 × 15.87 cm)
- Panel Thickness: 0.62″ (1.57 cm)
- Nominal Impedance: 8 Ω
- Power Handling: 30 W RMS
- Frequency Response: 80 Hz – 15 kHz ±6 dB
- Sensitivity: 89 dB SPL
- Certification: ETL Plenum Rated (UL2043 compliant)
What's Included
- 1x Williams AV SP-628L Lay-In Ceiling Speaker
- 1x Integrated metal back can
- Mounting T-bar supports
