Datavideo PD-2A Power Distributor with 110/220V
Datavideo PD-2A Power Distributor with 110/220V
Free Shipping
Datavideo PD-2A Power Distributor with 110/220V
Combine up-to 10 power supplies into a single power connection 400 watt rated power supply
Output connections: 4 x 3A + 2 x 5A + 2 x 10A 12V XLR DC
Technical Specifications
AC Input
100~240 VAC (50Hz or 60Hz)
AC input outlet: One AC input with Power Switch
DC Backup Input
One DC 12V/32A
supports non-regulated DC 12V output
DC Output
8
12V+/-5%, 3A XLR DC Female Jack x4
12V+/-5%, 5A XLR DC Female Jack x2
12V+/-5%, 10A XLR DC Female Jack x2
Max. Power Rating
400W
DC Overload
DC overload protection, auto-recovery fuses on each DC output terminal
AC Overload
non-recovery fuse on the AC input outlet
LED Indicator
8 DC output LED indicators
Power Source Input Select AUTO/AC
Selectable of Auto/AC input switch
Dimension (LxWxH)
484 x 217 x 49 mm
Weight
4.6 kg
Operating Temp. Range
0~40 C
Power
AC 100-240 VAC
DC 12V 400W
What's in the Box
1 x PD-2A product
1 x AC Cord
1 x Thank You Card
