Datavideo SE-2600 HD 8-Channel Digital Video Switcher
The Datavideo SE-2600 is an advanced 8-channel HD digital video switcher built for professional live event production. It seamlessly supports Full HD video standards and multiple input formats, making it ideal for live broadcasts, events, and e-sports. With four SDI and four HDMI inputs, it allows mixing HD and SD sources while offering advanced features such as chroma key, picture-in-picture, and logo insertion. The switcher provides unparalleled flexibility with its assignable outputs, robust audio support, and multi-view monitoring, ensuring smooth and dynamic production workflows.
Key Features:
- Supports Full HD resolution
- 8 live video inputs, 4x SDI and 4x HDMI
- Advanced chroma key, picture-in-picture, and stinger transitions
- Built-in multiview with SDI and HDMI outputs
- User-friendly control interface
Video Standard
Full HD
Video Format
Input: 1080p 50/ 59.94/ 60Hz, 1080i 50/ 59.94/ 60Hz, 720p 50/ 59.94/ 60Hz
Output: 1080p 50/ 59.94/ 60Hz, 1080i 50/ 59.94/ 60Hz, 720p 50/ 59.94/ 60Hz
Video Processing
SDI: 4:2:2, HDMI: YUV 4:2:2, RGB: 4:4:4
Input Routable / Crosspoint
YES
Video Input
4x SDI, 4x HDMI (Total 8 live inputs)
Mix HD & SD Source
YES
Computer Graphic Interface
4 via HDMI
Video Output
3x SDI, 3x HDMI (assignable to various sources)
Down-converted Output
1x SDI
Multi-view Monitoring Output
HDMI & SDI assignable
Analogue Audio Input
2x XLR/MIC, 1x Stereo RCA
Analogue Audio Output
1x Stereo RCA
Digital Embedded Audio
SDI (4 channels), HDMI (2 channels)
Audio Delay Calibration
Up to 16 fields/8 frames per channel
A+V Switching
YES
Chromakey
4
Title Creator
YES
USK
4x Keyer (Chromakey/ Linear/ Luma Key)
DSK
2x DSK (Lumakey & Linear key)
Picture-in-Picture
4 frames
Logo Insertion
2
Still Store
999+ (1080p)
Effects
Cut, Auto, WIPE, Mix, DVE, Stinger
Transition Preview
Full transitions preview
Sync / Reference In/Out
1x BNC Ref in, 1x BNC Ref out
Tally Output
1x D-sub 25pin, dual color
PC Remote Control
RS-232 / DVIP (Ethernet)
Firmware Update
USB
Chassis
Unibody
Dimensions (LxWxH)
431 x 313.2 x 84 mm
Weight
3.8 kg
Power
DC 12V, 82W
Operating Temp. Range
0~40 Ā°C
What's in the Box
SE-2600, AD Switch DC 12V, AC Cord
