Datavideo SE-500HD 4-Channel 1080p HDMI Video Presentation Switcher
Datavideo SE-500HD 4-Channel 1080p HDMI Video Presentation Switcher
Free Shipping
Datavideo SE-500HD 4-Channel 1080p HDMI Video Presentation Switcher
Scale mixed resolution/standards inputs up to 1080p.
HDMI 1080p switching with advanced features, at a fraction of the cost
Don't let the SE-500HD fool you with its affordability and compact design. This 1080p switcher comes loaded with features such as luma key for graphic overlays, split screen for podcast interviews, and PiP for Powerpoint presentations.
Built-in audio mixer
The SE-500HD's built-in audio mixer means that you've got everything you need to control your audio input levels. For most productions, this means that there's no need to buy a separate external audio mixer.
Supports lumakey for titles
With built-in lumakey, user can use PPT to easily create titles by graphic overlays.
User memories
You can save a complex process into a user memory, turning multiple tasks into a one-finger job.
Supports Vertical video multiview
It's an ideal solution for the videos on social media. The vertical video is more favorable while playing on the mobile device.
Professional 10-bit processing switcher
Providing you the best and professional quality of video processing.
Technical Specifications
Video Standard
Full HD & SD
Video Format
1080p 50/59.94/60Hz
1080i 50/59.94/60Hz
720p 50/59.94/60Hz
576i 50Hz
480i 59.94Hz
Video Processing
HDMI: YUV 4:4:4 10 bit, RGB: 4:4:4
Video Input
4x HDMI
Mix HD & SD Source
Yes
Computer Graphic Interface
4 via HDMI
Video Output
2 x HDMI (1 is MV, 1 is PGM)
Down-converted Output
Yes
Built-in Multi-view Monitoring Out
HDMI
Analogue Audio Input
1 x Stereo RCA (L/R)
2 x Mono Microphone
Analogue Audio Output
1 x Stereo RCA (L/R)
1 x Stereo headphone (Mini Jack with volume control)
Embedded Audio Support
Input 2 channels, Output 2 channels
A+V Switching
Yes
USK
Lumakey
Picture in Picture
1
Effects
FTB, Cut, Wipe with border
Sync / Reference In/Out
Built-in Genlock (internal)
Tally Output
1x D-sub 15pin, dual color
Built-in Audio Mixer
Yes, 4 channels
Special Features
Built-in video scaler for mixed resolution inputs
Chassis
Unibody
Dimension (LxWxH)
400 x 250 x 82 mm
Weight
1.7 kg
Power
DC 12V, 29W
Operating Temp. Range
0~40 C
Options
CB-46/47/60/61/62
What's in the box
1 x SE-500HD product
1 x AD Switch DC 12V with AC Cord
1 x Thank You Card
