Datavideo TLM-700UHD 7-Inch 4K LCD Monitor
Free Shipping
Datavideo TLM-700UHD 7-Inch 4K LCD Monitor
Datavideo's TLM-700UHD LCD Monitor accepts 4K 50/60p inputs and displays them on a 7” screen. The monitor is a 1920x1080 Full HD panel which provides 170 of viewing angle. The field monitor supports both DCI 4K and Ultra HD signal inputs and outputs.
7'' 4K Look-Back Monitor
Supports 4K/3G/HD/SD 1920x1200 panel resolution.
Simple Input and Output Configuration
1x HDMI input and loop out
Compatible with Professional Cameras
Compatible with DSLRs, mirrorless cameras, and camcorders
Fast and Accurate Focus Peaking
The red/green/blue peaking profile helps users instantly determine proper focusing.
Peaking zones can be shown during shooting, recording, and playback.
Over-Exposure Analysis
Exposure analysis lets users see if the brightness is too strong in certain regions of the video.
Color Field Checking
Provides monochrome, red, green and blue-only mode for easy color recognition and correction
Screen Flip Function
Supports both vertical and horizontal rotation. Compatible with tripods, arms, and cages. Convenient for viewing from multiple angles.
Zoom In
Zoom in 1.5X / 2X / 3X / 4X
Clearly view the details of image for instant adjustment
Safety Marker and Aspect Marker
Simulates the effect of cropping in post-production. Support vertical mode, too. Safety marker 95% / 93% / 90% / 88% / 85% / 80% and aspect maker 16:9 / 1.85:1 / 2.35:1 / 4: 3 / 3:2
Technical Specifications
Screen
7" TFT LCD
Chassis
Camera Mount
Resolution
1920x1200
Viewing Angle
(H) +85/-85
(V) +85/-85
Luminance/Contrast
450cd/m2
1000:1
Video Inputs
1x HDMI (2.0)
HDCP 2.2
Loop Through
1x HDMI (2.0)
Supported Input Resolutions
4096x2160p (23.98/24/25/29.97/30/50/59.94/60Hz)
3840x2160p (23.98/24/25/29.97/30/50/59.94/60Hz)
2048x1080p (50/59.94/60Hz)
1080p (23.98/24/25/29.97/30/50/59.94/60Hz)50i/59.94i/60i)
1080i (50/59.94/60Hz)
720p (23.98/24/25/29.97/30/50/59.94/60Hz)
576i(50Hz), 576p(50Hz),
480i(59.94/60Hz), 480p(59.94/60Hz)
Aspect Ratio
Full/16:9/1.85:1/2.35:1/4:3/3:2
Aspect Marker
Full/16:9/1.85:1/2.35:1/4:3/3:2
Safty Marker
Off/95%/93%/90%/88%/85%/80%
Audio In/Out
Embedded Audio (48KHz sampling)
Analog Stereo (Phone Jack),
Speaker x1 (2W)
Special Features
Focus assist (peaking)
False Color
Histogram
Exposure
Pixel to Pixel Zoom
Underscan
Check Field (blue-only mode, mono chrome mode)
Dimension (LxWxH)
182 x 129 x 37 mm
Weight
0.3 kg
Operating Temp. Range
0~40 C
Power
DC 12V, 12W
What's in the Box
1 x TLM-700UHD product
1 x AD Switch DC 12V
1 x Folding sun shade cover
1 x HDMI A/C cable
1 x Battery plate
1 x Hot shoe mount
1 x Thank You Card
