Defender 85002 3-Channel Cable Protector

Featuring a 73 mm profile, 45 curve and end ramps with detachable dovetail connectors the Defender 3 cable protection system provides versatile cable routing and safe crossing for vehicles and pedestrians. With 3 medium large channels, built-in handles for easy portability and a 5 t per 20 x 20 cm load capacity the 73 mm profile Defender 3 cable protectors are the perfect all-round choice for a wide variety of applications including heavy wheeled traffic, construction sites, warehouses, carnivals, fairs, trade shows, exhibitions, shopping malls and music events.

Key Features

• Heavy-duty,non-slip all-round cable protector made of black, recyclable polyurethane with built-in carrying handles
• Yellow polyethylene lid with high warning effect and secure closure
• Patented, self-cleaning lid hinge
• 3 channels: 1 channel 45 x 50 mm, 2 channels 52 x 49 mm
• Load bearing capacity approx. 5 t / 20 x 20 cm
• Fire resistance class B2 (DIN 4102), DEKRA-certified (DIN 31000, EN 61537)
• Resistant to oil, acid, petrol and short-term contact with solvents
• Dimensions 105 x 60.5 x 7.3 cm; Weight 23.7 kg
• Reliable protection for cables and personnel for indoor and outdoor use
• Curves, end ramps, and connector plugs are available as accessories

Technical Specifications

Product type
Cable Protectors
Type
3 Channels
Width
605 mm
Height
75 mm
Length
1005 mm
Channels
3
Width channel 1
52 mm
Height channel 1
49 mm
Width channel 2
45 mm
Height channel 2
50 mm
Width channel 3
56 mm
Height channel 3
49 mm
Material
Polyurethane
Max load
approx. 5 t on a surface area of 20 x 20 cm
Chemical resistance
acid-resistant , oil-resistant , Petrol-resistant , Short-term contact with solvents
Hardness range
88 Shore +/- 4 Shore
Fire protection class
B2
Temperature range
-40 to +70 C
Weight
22,82 kg
Special feature
available also in B1 , DEKRA-certified , Inclusive 2 connector plugs
