Digital Forecast Bridge 1000 SDA HD/SDI 4 x 1 Selector Distribution Amplifier
Digital Forecast | SKU: DIGIT-BRIDGE1000SDA
Loading...
$40500
Free Shipping
Unit price
/
Unavailable
More finance options:
Estimated Shipping Widget will be displayed here!
Enjoy free standard shipping on all orders over $99. Please note that this offer excludes oversized, overweight, special orders, custom products, and items with minimal profitability.
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Orders placed between Monday - Friday before
1:00 PM PST will most likely ship out the same day. We work hard to process and ship your items quickly so you can start enjoying them as soon as possible.
Found a lower price? Contact us and we'll see if we can match it! Price match will only be applied to products sold and shipped by authorized retailers of the brand.
No restocking fee will be charged when you opt for store credit. Exclusions apply.
Condition: New
Description
Digital Forecast Bridge 1000 SDA HD/SDI 4 x 1 Selector Distribution Amplifier
Bridge 1000_SDA is SDI 4 x1 Selector distributor. The selected SDI signal is output as four SDI signals. It'supports up to 1080p60 format, remote control is possible with RS-232 communication or RS-422.
Key Features
- HD/SDI 4 x1 Selector DA
- 4 HD/SDI Select input ( SD/HD/3G )
- 1 Selected source to 4 HD-SDI out ( SD/HD/3G )
- RS422 or RS232 remote control enable
- DC 7V ~ 24V wide operating range
Technical Specifications
Physical
Dimension (W x H x D)
106 x 96 x 30 (mm)
Weight
225 g
Power Level
+12 VDC
Power Consumption
4.27Watts (Max : 5Watts)
Humidity
0 to 95% RH, non-condensing
Supports multi-rate SDI formats
SMPTE 125M: NTSC (480i 59.94), PAL (576i 50)
SMPTE 296M: 720p (60/59.94/50)
SMPTE-274M,SMPTE-292M: 1080i (60/59.94/50)
1080p (30/29.97/25/24/23.98)
SMPTE-424M: 1080p (60/59.94) 3G
