PXM PX292 1-Channel DMX to 4-20V Converter
PXM PX292 1-Channel DMX to 4-20V Converter
Free Shipping
PXM PX292 1-Channel DMX to 4-20V Converter
PX292: The Solution for DMX-512 Signal Processing
Need a device that can decode DMX signals and provide analog 4-20 mA control? Look no further than the PX292. This compact tool is designed for easy installation in electric panels on DIN T35. Not only does it decode DMX signals, but it also enables you to program the unit's reaction to a loss of DMX signal. With individually programmable parameters, you can define each channel's DMX address in the range of 1-512, allowing multiple channels to be assigned to a single address.
Key Features
- PX292 is a top-tier DMX-512 Signal Processor, facilitating DMX-512 signal processing for refined 4 - 20 mA control.
- Delicately encased and perfect for installation in electric panels on DIN T35.
- Advanced features allow unit reaction programming in response to DMX signal loss.
- Comes with individually programmable parameters, defining independent DMX addresses ranging from 1-512 for each channel.
- Flexibility of assigning multiple channels to a single address.
Technical Specifications
DMX IN/OUT lines
1/1
DMX IN/OUT channels
512/512
4-20mA IN/OUT ports
0/8
Output Connectors
terminal blocks
Maximum Current Consumption
190 mA
Power Supply
24V DC
Weight
0.14 kg
Dimensions
70 (4 DIN rail modules) x 86 x 60 mm
