DVDO 4K 4x2 Presentation Switcher with USB-C and HDMI Inputs

The DVDO USB-C HDMI PS42 is a powerful 4x2 presentation switcher and scaler, designed to meet the demands of professional AV setups. Featuring two HDMI inputs, two USB-C inputs, and two HDMI outputs, it offers seamless connectivity and versatility for modern video and audio applications. With advanced features like USB-C charging, HDMI audio de-embedding, and multiple control options, this device is perfect for boardrooms, classrooms, and home theaters.

This presentation switcher supports resolutions up to 4K@60Hz with 4:4:4 chroma sampling for HDMI inputs and up to 4K@30Hz for USB-C inputs. The first USB-C port provides 65W charging, while the second delivers 10W, making it ideal for powering and connecting laptops or mobile devices. The device includes four USB 3.2 Type-A ports for peripherals such as cameras, KVMs, and speakerphones, as well as two USB 3.2 Type-B ports for host switching. With robust EDID management and support for DP 1.2 MST, the PS42 ensures a smooth and efficient video experience.

Control is a breeze with multiple options including IP, RS-232, CEC, and front panel buttons. Additionally, the dual HDMI outputs offer flexibility with conference, matrix, mirror, and manual modes, as well as the ability to downscale 4K to 1080p. Compact and feature-packed, the DVDO USB-C HDMI PS42 is the ultimate solution for dynamic video switching and scaling.

Key Features

• 4x2 switcher with 2 HDMI inputs, 2 USB-C inputs, and 2 HDMI outputs
• Supports HDMI resolutions up to 4K@60Hz 4:4:4 at 18Gbps
• USB-C inputs support up to 4K@30Hz and DP 1.2 MST function
• First USB-C input provides 65W charging; second USB-C input provides 10W charging
• Audio de-embedding with a separate audio output
• 4 USB 3.2 Gen 1 ports for peripherals and 2 USB 3.2 Type-B ports for host switching
• Flexible HDMI output modes: conference, matrix, mirror, and manual
• 4K to 1080p downscaling
• Control via IP, RS-232, CEC, or front panel buttons
• Firmware upgrades via TCP/IP

Technical Specifications

Video Input: 2 x HDMI, 2 x USB-C
Video Input Connector: Type-A female HDMI, Type-C USB 3.2
Video Input Resolution:
- HDMI: Up to 4K@60Hz 4:4:4 8bit
- USB-C: Up to 4K@30Hz, DP1.2 MST function

Video Output: 2 x HDMI
Video Output Connector: Type-A female HDMI
Video Output Resolution: Up to 4K@60Hz 4:4:4, supports 4K to 1080P down-scaling
HDMI Version: Up to 2.0
HDCP Version: Up to 2.2

Downscaling Capability:
- 4K 60Hz 4:4:4/4:2:0 to 1080p 60Hz 4:4:4
- 4K 50Hz 4:4:4/4:2:0 to 1080p 50Hz 4:4:4
- 4K 30Hz 4:4:4/4:2:0 to 1080p 30Hz 4:4:4
- 4K 25Hz 4:4:4/4:2:0 to 1080p 25Hz 4:4:4
- 4K 24Hz 4:4:4/4:2:0 to 1080p 24Hz 4:4:4

Audio Formats:
- Pass-through: LPCM 7.1, Dolby® TrueHD, Dolby Digital® Plus, DTS-HD® Master Audio™
- De-embedding: PCM 2.0 on 5-pin terminal block

Control:
- USB: 2x USB Type-C (65W and 10W charging), 2x USB Type-B, 4x USB Type-A
- RS-232: 1 x 3-pin terminal block
- Ethernet: 1x 100Base-T on RJ45 port

General:
Operating Temperature: -5°F ~ 131°F
Storage Temperature: -13°F ~ 158°F
Relative Humidity: 10%-90%
External Power Supply: Input: AC 100~240V, 50/60Hz; Output: 20V DC 5.0A, 100Watt
Power Consumption: 85W (Max)

Dimensions: 10.2" x 1.0" x 6.1"
Net Weight: 2.1 lbs
Gross Weight: 3.9 lbs

What’s Included

• 1 x DVDO-USBC-HDMI-PS-42

• 2 x Mounting Ears with 4 Screws

• 4 x Rubber feet

• 1 x RS232 Cable (3-pin to DB9)

• 1 x 5-pin phoenix connector

• 1 x 100Watt USB-C Power Supply (20V 5A)

• 1 x User Manual
