DVDO 8K 4x1 Switcher with 1 USB-C + 3 HDMI Inputs

The DVDO 8K 4x1 Switcher provides seamless connectivity for up to four devices, including three HDMI and one USB-C input. Perfect for home theaters, conference rooms, or any space requiring high-quality video and audio switching, this compact device supports resolutions up to 8K at 60Hz with 4:4:4 color, ensuring sharp visuals. Whether you are switching between gaming consoles, laptops, or media players, the switcher delivers a smooth, high-performance experience with automatic or manual switching options.

Designed with modern compatibility in mind, the switcher supports a broad array of video formats, including HDR10, HDR10+, and Dolby Vision for stunning contrast and vibrant colors. It also supports high-definition audio formats such as uncompressed LPCM and compressed formats like DTS-HD Master Audio and Dolby Atmos. The addition of USB-C and USB-A ports allows you to charge devices simultaneously, making it an excellent choice for both entertainment and productivity setups.

With a sleek black metal enclosure, the DVDO 8K 4x1 Switcher offers reliable operation in temperatures ranging from 32°F to 122°F and features easy-to-use controls via an IR remote, front panel button, or CEC. This versatile device ensures that your home theater or AV system operates flawlessly and efficiently, making it a must-have for anyone needing advanced HDMI switching with top-tier audio and video capabilities.

Key Features:

• Supports up to 8K@60Hz 4:4:4 resolution, with a bandwidth of 48Gbps
• Compatible with HDMI 2.0b, HDCP 2.3, and HDR formats including Dolby Vision
• Three HDMI inputs and one USB-C input for seamless device connectivity
• USB-C input compatible with Thunderbolt 3 and DP 1.4 alt mode
• Supports uncompressed LPCM and compressed DTS, Dolby Digital, DTS-HD Master Audio, Dolby TrueHD, and Dolby Atmos audio formats
• Manual and automatic switching via IR remote, front panel button, or CEC
• Two USB charging ports (1 x USB-C + 1 x USB-A) supporting up to 5W (not simultaneous)

Technical Specifications:

Dimensions: 5.5" x 2.5" x 0.6" (W x D x H)
Weight: 0.42 lbs

HDMI Compliance: HDMI 2.0b, HDCP 2.3/2.2/1.4
Inputs: 3 x HDMI, 1 x USB-C (compatible with Thunderbolt 3 & DP 1.4 alt mode)
Output: 1 x HDMI
Charging Ports: 1 x USB-C + 1 x USB-A (up to 5W, not simultaneous)

Resolutions Supported: Up to 8K@60Hz 4:4:4, 4K@120Hz, 1080p@240Hz
Bandwidth: 48Gbps (12Gbps per channel x 4 channels)
High Dynamic Range: HDR10, HDR10+, Dolby Vision
Audio Formats Supported: Uncompressed LPCM, Compressed DTS, Dolby Digital, DTS-HD Master Audio, Dolby TrueHD, Dolby Atmos

Control Method: IR Remote, Front Panel Button, Automatic Switching, CEC
Operating Temperature: 32°F to 122°F (0°C to 50°C)
Humidity: 5% to 80% RH, non-condensing
Power Supply: 5V 2A USB-A power adapter
Power Consumption: 10W Max

What’s Included:

• DVDO 8K 4x1 Switcher
• IR Remote Control
• 5V 2A USB-A Power Adapter
• Quick Start Guide
